Lexicon MPX 200 Service Manual page 52

MPX 200 Service Manual
PART NO. DESCRIPTION
245-00596 CAP,CER,.005uF,1.6KV,Z5U
245-09291 CAPSM,CER,470pF,50V,COG,5%
245-09876 CAPSM,CER,.01uF,50V,Z5U,20%
245-09895 CAPSM,CER,10pF,50V,COG,10%
245-10416 CAPSM,CER,1000pF,50V,COG,5%
245-10544 CAPSM,CER,220pF,50V,COG,5%
245-10561 CAPSM,CER,100pF,50V,COG,5%
245-10562 CAPSM,CER,150pF,50V,COG,10%
245-10976 CAPSM,CER,47pF,50V,COG,5%
245-11625 CAPSM,CER,33pF,50V,COG,5%
245-11949 CAPSM,CER,1500pF,50V,COG,5%
245-12485 CAPSM,CER,.1uF,25V,Z5U,20%
270-06671 FERRITE CHOKE,2.5 TURN
270-11545 FERRITESM,CHIP,600 OHM,0805
300-10509 DIODESM,1N914,SOT23
300-10563 DIODESM,DUAL,SERIES,GP,SOT23
300-11599 DIODESM,GP,1N4002,MELF
310-01007 TRANSISTOR,2N3904
310-01008 TRANSISTOR,2N3906
310-10510 TRANSISTORSM,2N3904,SOT23
310-10565 TRANSISTORSM,2N3906,SOT23
330-10523 ICSM,DIGITAL,74HCU04,SOIC
330-11990 ICSM,LEXICHIP3B,100PIN,PQFP
330-12452 ICSM,DIGITAL,74VHCT244,SOIC
330-12845 ICSM,DIGITAL,74HC157,SOIC
330-14244 ICSM,DIGITAL,74VHCT138,SOIC
330-14642 ICSM,DIGITAL,74VHCT14,SOIC
340-10877 ICSM,LIN,4556,DUAL OP AMP,SOIC
340-11573 ICSM,LIN,NJM4580,DUALOPAMP,SOP
340-11576 ICSM,LIN,7905,-5V REG,TO263
340-13540 IC,LINEAR,LM2940C,5V REG,TO220
340-14643 ICSM,LIN,3.3V REG,LOPWR,SOT23
345-14649 ICSM,RCVR,AK4112,24B,96k,VSOP
346-10508 ICSM,SS SWITCH,74HC4053,SOIC
350-10545 ICSM,SRAM,8KX8,80NS,SOIC,50uA
350-12637 ICSM,DRAM,1MX16,70NS,SOJ
350-14158 ICSM,EEPROM,24C32,32K,SER,SOIC
350-14748 ICSM,FLASH,2M,MPX200,V1.02
355-12045 ICSM,CODEC,AK4528,24B,96k,VSOP
365-09883 ICSM,uPROC,Z80,CMOS,10MHz,QFP
375-02247 IC,OPTO-ISOLATOR,6N138
390-12361 CRYSTALSM,11.2896MHz,PAR,HC49
440-14647 FUSE,5X20MM,SLO-BLO,.250A
451-14648 SW,SL,2P2T,115/230V-SEL,PCRA
452-14617 SW,RTY,ENC,16POS,4BIT,GRY,20MM
470-14727 XFORMER,PCMT,115/230V,10V,1.9A
510-07888 CONN,AC,3MC,PCRA,IEC,10A
510-09790 CONN,DIN,5FC@180DEG,PCRA,SHLD
510-11087 1/4"PH JACK,PCRA,3C,SW-TR,G,FT
510-11548 1/4"PH JACK,PCRA,2C,SW-T,G,FT
510-13149 CONN,RCA,PCRA,1FCGX2V,WH/RED,G
600-02227 FUSE CLIP,20MM,PC
630-14670 WSHR,FL,#4CLX1/4ODX1/32,NYL
640-07899 SCRW,4-40X1/2,PHN,PH,ZN
643-01732 NUT,4-40,KEP,ZN
650-03970 POPRVT,1/8X1/8,REG PROT HD,SS
675-09102 WIRE,22G,BLU,3.5",.187QDC/ST
675-09103 WIRE,22G,BRN,3.5",.187QDC/ST
675-14137 WIRE,18G,GRN/YEL,7",#6RING/SS
701-14147 BRACKET,KEYSTONE,633,.140DX2
704-14132 HEATSINK,TO220,.75X.5X.5"H
7-2
QTY EFFECTIVE • INACTIVE
1.00
4.00
3.00
3.00
1.00
4.00
9.00
6.00
2.00
2.00
2.00
44.00
2.00
2.00
2.00
7.00
3.00
1.00
1.00
1.00
1.00
1.00
1.00
2.00
1.00
1.00
1.00
1.00
4.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
2.00
2.00
3.00
1.00
2.00
2.00
2.00
2.00
1.00
1.00
1.00
1.00
1.00
1.00
REFERENCE
C11
C31,32,35,36
C67,100,103
C1,16,74
C116
C26,45,61,71
C5,8,20,23,49,56
C110-112
C28,47,63,73,123,124
C102,104
C76,77
C41,42
C3,4,13-15,18,19,33
C34,38,40,43,52-55
C65,69,70,75,78-82
C86,87,89-91,93
C95-99,101,105-107
C113-115,117
FB1,3
FB4,5
D4,7
D1-3,5,6,8,9
D10-12
Q2
Q1
Q4
Q3
U18
U10
U15,23
U9
U22
U14
U6
U1-4
U11
U25
U12
U13
U7
U16
U17
U8
U20
U5
U19
U24
Y1
F1
SW2
SW1
T1
J9
J6,7
J4,8
J1-3
J5
F1
J9 (AC CONN)
BOTTOM OF PCB
J9 (AC CONN)
BOTTOM OF PCB
J9 (AC CONN)
KEY1
J10
J11
AC CONN TO FP
KEY1
U10
