Chapter 7 - Pa r ts List

MPX200 MAIN BOARD ASSEMBLY

PART NO. DESCRIPTION
120-14142 ADHESIVE,EPOXY,THERM COND
200-12169 POT,RTY,5K15AX2,7MMFL,14,15L
202-09794 RESSM,RO,0 OHM,0805
202-09795 RESSM,RO,5%,1/10W,2.2K OHM
202-09873 RESSM,RO,5%,1/10W,10K OHM
202-09894 RESSM,RO,5%,1/10W,1M OHM
202-09897 RESSM,RO,5%,1/10W,470 0HM
202-09899 RESSM,RO,5%,1/10W,47 OHM
202-10466 RESSM,RO,5%,1/10W,20K OHM
202-10557 RESSM,RO,5%,1/10W,4.7K OHM
202-10558 RESSM,RO,5%,1/10W,47K OHM
202-10559 RESSM,RO,5%,1/10W,100 OHM
202-10569 RESSM,RO,5%,1/10W,10 OHM
202-10597 RESSM,RO,5%,1/10W,180 OHM
202-10892 RESSM,RO,5%,1/10W,2K OHM
202-11041 RESSM,RO,5%,1/10W,680 OHM
202-11071 RESSM,RO,5%,1/4W,75 OHM
202-11072 RESSM,RO,5%,1/4W,220 0HM
202-11073 RESSM,RO,5%,1/4W,270 OHM
202-11683 RESSM,RO,5%,1/10W,5.1 OHM
202-12836 RESSM,RO,5%,1/10W,2.7K OHM
202-14619 RESSM,RO,5%,1/10W,18K OHM
203-10424 RESSM,RO,1%,1/10W,4.99K OHM
203-10581 RESSM,RO,1%,1/10W,3.32K OHM
203-10583 RESSM,RO,1%,1/10W,10.0K OHM
203-10840 RESSM,RO,1%,1/10W,750 OHM
203-10894 RESSM,RO,1%,1/10W,340 OHM
203-10896 RESSM,RO,1%,1/10W,1.00K OHM
203-10991 RESSM,RO,1%,1/10W,1.40K OHM
203-11075 RESSM,RO,1%,1/10W,95.3 OHM
203-11079 RESSM,RO,1%,1/10W,715 OHM
203-11083 RESSM,RO,1%,1/10W,49.9K OHM
203-11723 RESSM,RO,1%,1/10W,4.75K OHM
203-11734 RESSM,RO,1%,1/10W,4.32K OHM
203-12167 RESSM,RO,1%,1/10W,374 OHM
203-12198 RESSM,RO,1%,1/10W,2.15K OHM
203-12199 RESSM,RO,1%,1/10W,316 OHM
203-12491 RESSM,RO,1%,1/10W,205 OHM
203-13918 RESSM,THIN,.1%,1/10W,4.02K OHM
240-00611 CAP,ELEC,22uF,16V,RAD
240-00614 CAP,ELEC,47uF,16V,20%,RAD
240-06611 CAP,ELEC,1000uF,25V,20%,RAD
240-06886 CAP,ELEC,4.7uF,25V,20%,AX
240-09786 CAP,ELEC,100uF,25V,RAD,LOW ESR
240-12330 CAPSM,ELEC,2.2uF,35V,20%
240-12848 CAP,ELEC,3300uF,16V,20%,RAD
241-00654 CAP,TANT,22uF,16V,RAD
244-00661 CAP,MYL,.047uF,5%,RAD,BOX
244-10423 CAP,MYL,.22uF,50V,RAD,5%,BOX
244-10768 CAP,MYL,.015uF,250V,INTL,.6SP
244-14616 CAP,MYL,3300pF,100V,RAD,5%,BOX
QTY EFFECTIVE • INACTIVE
0.00
1.00
19.00
2.00
31.00
3.00
2.00
12.00
4.00
2.00
8.00
4.00
1.00
12.00
2.00
1.00
3.00
3.00
1.00
1.00
1.00
1.00
2.00
1.00
3.00
2.00
4.00
1.00
2.00
1.00
2.00
1.00
13.00
2.00
2.00
2.00
2.00
4.00
1.00
18.00
2.00
1.00
1.00
2.00
1.00
2.00
2.00
2.00
2.00
1.00
2.00
Lexicon
REFERENCE
U10 HEATSINK
R1
R72,82,94
R96-98,102,105-108
R112,146,147,156,165
R166,172,173
R128,149
R65,67,73,74,76
R83-90,92,99,100
R113-121,142-145
R154,157
R7,22,91
R54,56
R130-141
R12,13,27,28
R168,170
R81,126,158-161
R169,171
R6,19,68,127
R75
R69-71,77,80,93,95
R101,103,104,109,111
R55,57
R66
R59,79,129
R148,150,164
R163
R46
R162
R110
R37,41
R15
R48,49,62
R4,20
R10,11,25,26
R60
R51,52
R123
R124,125
R63
R8,9,14,23,24,30-32
R36,40,42-44
R3,18
R2,17
R50,53
R5,21
R34,35,38,39
R61
C2,7,9,10,12,17,22
C24,25,44,50,51,57
C58,68,85,88,92
C59,60
C122
C84
C64,94
C39
C127,128
C66,131
C6,21
C29,48
C130
C30,37
7-1
