Technaxx TX-94 User Manual

Bluetooth led record & cd digitizer
Hide thumbs Also See for TX-94:

Advertisement

Quick Links

Bluetooth LED Record & CD Digitizer TX-94
The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares that this device,
to which this user manual belongs, complies with the essential requirements of the
standards referred to the Directive RED 2014/53/EU. The Declaration of Conformity you
find here: www.technaxx.de/ (in bar at the bottom "Konformitätserklärung"). Before using
the device the first time, read the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 cent/minute from German
Keep this user manual for future reference or product sharing carefully. Do the same with
the original accessories for this product. In case of warranty, please contact the dealer or
the store where you bought this product. Warranty 2 years
Before usage
Choose the installation location of your unit carefully. Avoid placing it in direct sunlight or
close to a source of heat. Also avoid locations subject to vibrations and excessive dust,
heat, cold or moisture.
Do not install the unit in a inclined position, It is designed to be operated in a horizontal
position only.
If the unit is brought directly from a cold to a warm location, moisture may condense
inside the player, and cause damage it. When you first install the unit, or when you move it
from a cold to a warm location, wait for 30 minutes before operating the unit.
The ventilation holes should not be covered. Make sure there is enough space above
and beside the amplifier/receiver. Do not place a CD player or other equipment on top of
the device.
Do not open the cabinet. This might cause a damage to circuitry or electrical shock.
If you are not going to use the player for long time, be sure do disconnect the player
from the AC power source. When removing the power plug, never yank the cord.
To prevent fire or shock hazard, disconnect your unit from the AC power source when
cleaning. Use caution when cleaning and wiping the plastic parts. Do not attempt to clean
the unit with the chemical solvents as this might damage the finish.
Technaxx
fixed-line and 42 cent/minute from mobile networks).
Free Email: support@technaxx.de
®
* User Manual

Advertisement

loading

Summary of Contents for Technaxx TX-94

  • Page 1 * User Manual Bluetooth LED Record & CD Digitizer TX-94 The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares that this device, to which this user manual belongs, complies with the essential requirements of the standards referred to the Directive RED 2014/53/EU. The Declaration of Conformity you find here: www.technaxx.de/ (in bar at the bottom “Konformitätserklärung”).
  • Page 2: Technical Specifications

    Material MDF + PVC + Plastic Weight / Dimensions 3.62kg / (L) 34.2 x (W) 31.7 x (H) 17.0cm Bluetooth LED Record & CD Digitizer TX-94, Adapter for Single Package Contents records with 45 RPM, Euro power adapter, User Manual...
  • Page 3 Front View & Rear View & Top View Tuning knob for FM frequency USB port Standby indicator STOP button Standby button REC button Function button Bluetooth indicator PREV button (fast backwards) REC indicator NEXT button (fast forwards) Open/Close CD slot PLAY/PAUSE button Volume control knob (VOLUME) 15 Antenna...
  • Page 4 Top View 22 45 RPM adapter AUTO STOP switch ON/OFF switch 23 Turntable platter 24 Speed selector Tone arm lock 25 Tone arm Tone head Installation CAUTION: To avoid stylus damage, make certain the included stylus guard is in place whenever the turntable is being installed, moved, no being used or cleaned.
  • Page 5 Recording preparation Formate a USB flash drive (max. 32GB) with your PC to FAT32. Plug this USB flash drive into the USB port of the TX-94. Now you can start the recordings. Listen to FM radio Press "Standby" button [4] to turn on the unit from above, not from the front.
  • Page 6 Turn on your Bluetooth function on your mobile phone or tablet PC and then search the turntable player with its name “TX-94”. After pairing and connection, the Bluetooth indicator [11] will become blue and stops flashing. Now you can play music of your mobile phone or tablet PC via Bluetooth connection.
  • Page 7 Connect one side of the RCA connection cable* (*not included) to a stereo system or an amplifier with loudspeaker and the other side to your RCA outputs of the TX-94. Now you can listen to music played by your TX-94 over your audio home system.
  • Page 8 Cleaning: Protect the device from contamination and pollution (use a clean drapery). Avoid using rough, coarse-grained materials or solvents/aggressive cleaner. Wipe the cleaned device accurately. Distributor: Technaxx Deutschland GmbH & Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany...
