Summary of Contents for Competition Electronics ProTimer BT
- Page 2 We are here to help, if you have any questions or comments, please contact us at 815-874-8001 www.competitionelectronics.com. The ProTimer BT is designed and built in the USA. With proper use and care it will give you many years of trouble-free service.
-
Page 3: Table Of Contents
Pro Timer Table of Contents 7-13 Battery Installation......Power ON/OFF........Home Screen Information....9-10 Control Button Functions....LED and Beeper Alerts...... Headset Jack........Basic Operation........ Battery Status, info, and warning screens............ 13-14 Shot Detection........Memory Info..........Menu Flow List......... Resetting to Factory Defaults....Firmware update........ -
Page 4: Battery Installation
Pro Timer Battery Installation The ProTimer BT operates using a 9 volt battery for power. It is important to use Alkaline or Lithium batteries (not carbon) due to the power demand of the buzzer and display backlighting. Install the battery in the compartment on the rear of the unit. -
Page 5: Home Screen Information
Pro Timer Home Screen This screen is the default style which shows the time to last shot, time to the first shot, current split time, shot number, and date/time. 5.82 1.00 0.78 3:30PM SHOT# 5 Note: You can choose from two other screen configurations as shown on page # 10... -
Page 6: Control Button Functions
Pro Timer Control Button Functions START BUTTON (Located on the side of the unit), Press to start a new timing event. The timing begins from the moment the beeper sound is activated. INCR MENU BUTTONS (Marked on the front of the unit REV), these buttons navigate back and MENU forth through the continuous menu loop. -
Page 7: Led And Beeper Alerts
MENU LED & Beeper Alerts REV/OFF DECR/ON The ProTimer BT has two indicators for signaling an event. They are both active with the default settings, but can be turned off if desired within the menu settings. -
Page 8: Headset Jack
Shot Detection Each time a shot is detected, it will be added to the shot string. The ProTimer BT will automatically calculate the split time, which is the time between the current shot and the previous shot. -
Page 9: Menu Flow List
Pro Timer Menu List Moving forward from the home screen, here is the order of menu screens and a brief description. More detail for each is provided later in this manual. • Review shot string: shot number, time, and split information •... - Page 10 Pro Timer Individual Menu Screen Detail Review Shot String From the home screen, pressing MENU/FWD, SET/INCR, or SET/DECR will advance to the review screen. Shots will be displayed on the shot review screen in a “one shot per line” format. Reading from left to right, the shot time appears first, followed by the shot number, and finally the split time.
- Page 11 The par time settings create multiple beeps based on time intervals from the start beep. The ProTimer BT has the capacity for up to 5 par times which will automatically occur at the user settable time interval for each. The default settings are zero for all 5 par time settings, which effectively turns them off, so in this case there will be only the start beep at the beginning of an event.
- Page 12 Pro Timer Backlight ON Time The display backlighting can be set for a specific amount of time to remain ON after pressing a button. The settable range is 0 to 99 seconds. Longer time intervals will reduce battery life. Beeper/Headset Volume The volume control for beeper and headset volume can be adjusted from OFF to maximum with 10 levels.
- Page 13 SHOT# 9 3:30PM the first and the last shot. Shots recorded more than 199 .99 seconds after the start beep will render readings invalid until the unit is restarted. The ProTimer BT can detect shots at rates up to 1800 RPM.
- Page 14 The SHOT DEAD TIME feature is used to reduce false shot recordings due to echoes or ringing normally associated with indoor use. Once a shot is detected, the ProTimer BT will disregard subsequent shots (echoes) for a short period of time. The default setting is .11 seconds, but can be adjusted from .05 to .12 seconds.
- Page 15 • Search your device’s app store for “Competition Electronics PT Link” and install the app. • Turn on the ProTimer BT, and open the app - the app will automatically pair with your timer. There is a button in the app menu to re-attempt the pairing process.
-
Page 16: Battery Status, Info And Warning Screens
Pro Timer Clear Data Use the Clear Data screen to delete unwanted strings by pressing the START button. This cannot be reversed! Battery status, info and warning screens The battery icon shown on the display will appear as: -FULL from 8.4 to 9.5 volts -1/2 from 7.8 to 8.3 volts -EMPTY from 7.3 to 7.7 volts -FLASH/EMPTY from 6.5 to 7.2 volts... -
Page 17: Memory Info
25 hours of service. Memory info The ProTimer BT will retain up to 50 shot strings, with up to 70 shots per string, and all settable values in non-volatile memory, along with hit factor scoring. This means that they will not be lost during battery changes. If the maximum number of strings is exceeded, the oldest string will be purged automatically. -
Page 18: Specifications
Pro Timer Specifications • Operating Temperature: 30-110 degrees Fahrenheit • Accuracy: +/- .01 seconds • Max # of Shots Per String: 70 • Max # of Strings in Memory: 50 • Max # of Rounds per Minute: 1800 • Max # of Par Time Beeps: 5 •... -
Page 19: Warranty
Pro Timer Return Shipping Address: Contact Us: Competition Electronics, Inc. Phone: 815-874-8001 3469 Precision Dr. FAX: 815-874-8181 Rockford, IL 61109 competitionelectronics.com...
