Microwave Oven
KOR-1A1G
Instruction Manual
and Cooking Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KOR-1A1G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DAEWOO ELECTRONICS KOR-1A1G

  • Page 1 Microwave Oven KOR-1A1G Instruction Manual and Cooking Guide...
  • Page 2: Table Of Contents

    PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.
  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances, basic safety precautions should be followed, including the following: WARNING-To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy: 11. Read all instructions before using the appliance. 16.
  • Page 4: Federal Communications Commission Radio Frequency Interference Statement (U.s.a Only)

    FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT (U.S.A ONLY) WARNING: This equipment generates and uses ISM frequency energy and if not installed and used properly, that is in strict accordance with the manufacturer's instructions, may cause interference to radio and television reception.
  • Page 5: Installation

    INSTALLATION Examine the oven after unpacking. check fork damage such as a misaligned door, broken door or dent in the cavity. If any damage is visible, DO NOT INSTALL, and notify your dealer immediately. Level, flat location. Install the microwave oven on a level, flat surface. Ventilation Do not block air vents.
  • Page 6: Specifications

    SPECIFICATIONS POWER SUPPLY 120V AC 60 Hz SINGLE PHASE WITH GROUNDING POWER CONSUMPTION 1400 W MICROWAVE OUTPUT POWER 1000 W FREQUENCY 2450 MHz OUTSIDE DIMENSIONS (W X H X D) 539 x 300 x 406 mm (21.2 x 11.8 x 16.0 in.) CAVITY DIMENSIONS (W X H X D) 354 x 228 x 373 mm (13.9 x 9.0 x 14.7 in.) NET WEIGHT...
  • Page 7: Features Diagram

    FEATURES DIAGRAM TIMER LOCK lb 1.Bread POPCORN 2.Soup 3.Baked Potato MORE 4.Fresh Vegetable FROZEN 5.Frozen Vegetable PIZZA LESS AUTO DINNER COOK PLATE AUTO DEFROST MEAT POULTRY FISH 1 2 3 POWER 4 5 6 7 8 9 DEFROST KITCHEN CLOCK TIMER START/ STOP/CLEAR...
  • Page 8 FEATURES DIAGRAM (continued) TIMER LOCK 1.Bread POPCORN 2.Soup 3.Baked Potato MORE 4.Fresh Vegetable FROZEN 5.Frozen Vegetable PIZZA LESS AUTO DINNER COOK PLATE AUTO DEFROST MEAT POULTRY FISH 1 2 3 POWER 4 5 6 7 8 9 DEFROST KITCHEN CLOCK TIMER START/ STOP/CLEAR...
  • Page 9: Operation Procedure

    OPERATION PROCEDURE This section includes useful information about oven operation. 1. Plug power supply cord into a standard 3- pronged 20 Amp, 120V AC 60Hz power outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray and roller guide must always be in place during cooking.
  • Page 10: Controls

    CONTROLS SETTING THE CLOCK When the oven is first plugged in, the display will flash ":0" and a tone will sound. If the AC power ever goes off, the display shows ":0" when the power comes back on. 1. Touch CLOCK pad. NOTE: This oven has multiple clock This is a 12 hour clock system.
  • Page 11: Weight Defrosting

    WEIGHT DEFROSTING WEIGHT DEFROSTING lets you easily defrost food by eliminating guesswork in determining defrosting time. Follow the steps below for easy defrosting. 1. Touch MEAT pad. The Ib indicator lights and "1.0" is displayed. MEAT The display will show what you touched. 2.
  • Page 12: Cooking In One Stage

    COOKING IN ONE STAGE 1. Touch POWER pad. The M/W indicator lights and the “P-HI” is (Select desired power level.) displayed. POWER The display will show what you touched. This example shows power level 5. 2. Touch the number pads for the cooking time. NOTE: If steps 1nd 2 are omitted, the oven will cook at full power.
  • Page 13: Kitchen Timer Mode

    KITCHEN TIMER MODE Timer operates as a minute timer, can be set to delay cooking and used as a hold setting after cooking.However delay cooking can not be programmed for defrost. Timer operates without microwave energy. HOW TO USE AS A MINUTE TIMER 1.
  • Page 14: Speedy Cook

    SPEEDY COOK SPEEDY COOK allows you to reheat for 30 seconds at 100% (full power) by simply touching the SPEEDY COOK pad. By repeatedly touching the SPEEDY COOK pad, you can also extend reheating time to 5 minutes by 30 second increments. 1.
  • Page 15: Auto Cook

    ONE TOUCH COOKING (CONTINUED) 1. Put foods in the microwave plate. When you touch DINNER PLATE pad DINNER Cover with vented plastic wrap. once, "12" is displayed. PLATE 2. Touch DINNER PLATE pad After 1.5 seconds, the display shows the once for an 12 oz dinner plate or cooking time and the oven starts cooking.
  • Page 16: Less, More

    LESS, MORE To alter one touch cooking or cooking time whilst oven is in operation, use LESS or MORE.(except for defrosting) Press LESS/MORE to decrease/increase the one touch cooking time in multiples of 10 seconds. The overall one touch cooking time can be increased to a maximum of 99 minutes 50 seconds. Press LESS/MORE to decrease/increase the cooking time in multiples of 1 minute.
  • Page 17: Utensil Test

    UTENSIL TEST Dishes that do not absorb microwave energy are best for microwave cooking. Lock on the label to verify that particular cups, glasses, plates are indeed suitable, especially paper goods. If you are not sure, try this utensil test to check. •...
  • Page 18: Care Of Your Microwave Oven

    CARE OF YOUR MICROWAVE OVEN Turn the oven off before cleaning. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy water or in a dishwasher. Keep the inside of the oven clean. When food spatters or spilled liquids adhere to oven walls, wipe with a damp cloth.
  • Page 19: Use Your Microwave Oven Safely

    USE YOUR MICROWAVE OVEN SAFELY GENERAL USE Do not attempt to defeat or tamper with safety interlocks. Do not place any object between the oven front frame and the door or allow residue to build up on sealing surfaces. Wipe with a mild detergent, rinse and dry. Never use abrasive powders or pads. Do not subject the oven door strain or weight such as a child hanging on an open door.
  • Page 20: Before You Call For Service

    BEFORE YOU CALL FOR SERVICE Refer to following checklist, you may prevent an unnecessary service call. * The oven doesn't work; 1. Check that the power cord is securely plugged in. 2. Check that the door is firmly closed. 3. Check that the cooking time is set. 4.
  • Page 21: Cooking Chart

    COOKING CHART MEAT ITEM MICROWAVE POWER COOKING TIMER PER POUND Beef Standing/rolled Rib - Rare P-80 6-8 min. - Medium P-80 8-10 min. - well done P-80 10-12 min. Ground Beef(to brown for casserole) P-HI 6-8 min. Hamburgers, Fresh or defrosted (4 oz.
  • Page 22 VEGETABLE ITEM PREPARATION QUANTITY COOKING TIME STANDING TIME asparagus, fresh -in.pieces 1 lb. 5-6 min. 3 min. asparagus, frozen Whole spears 10 oz. pkg 6-7 min. 3 min. broccoli, fresh Spears 1 lb. 5-6 min. broccoli, frozen Whole or cut 10 oz.
  • Page 23 ITEM QUANTITY POWER LEVEL COOKING TIME SPECIAL INSTRUCTION 2 pieces P-HI 3-5 min. Arrange, on paper tower lined Fried chicken 4 pieces P-HI 4-6 min. paper plate, covered with paper 6 pieces P-HI 6-8 min. tower 2 fillets P-HI 2-3 min. Fried fresh fillets 4 fillets P-HI...
  • Page 24: Warranty

    Limited Warranty DAEWOO ELECTRONICS AMERICA, INC. warrants the following microwave ovens to be free from defective material and workmanship and agrees to remedy any such defect or to furnish a new part (at the Company's option) in exchange for any part of any unit of its...
