Rail King GP-20 Diesel Engine Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Compatibility
This engine will operate on any traditional
O-31 Gauge track system, including
M.T.H.'s RealTrax
traditional tubular track. It is also compatible
with most standard AC transformers. (See
page 21 for a complete list of compatible
transformers and wiring instructions.)
PLEASE READ BEFORE USE AND SAVE
GP-20 Diesel
Engine
OPERATOR'S MANUAL
®
™
or ScaleTrax
or
