LEGRAND HKT1 Installation Instructions

Catalog Number(s): HKT1
Doc number 1507326 – Rev A

Getting to Know Your Device

• This kit includes:
o 2m (6.5ft) self-adhesive light strip
o Controller
o Power adaptor (24V, 1.25A)
• The strip can be shortened by cutting at designated locations to a minimum length of 34cm (1.1ft).
• The strip can be extended up to 10m (32.8ft) by adding extensions (HKT2). Each extension is 2m (6.5ft).
Item Name
1 Power Adaptor
2 Controller
3 6-Pin Connector
4 Point of Extension
Designated Locations for
5
Cutting
6 Reset Button
Smart LED Light Strip Kit White and Color with HomeKit Technology
Installation Instructions
Keep your individual HomeKit Setup Code in a secure area. The code is
unique to your device.
Description
24VDC, 1.5A supply – For indoor use only
Connects to the strip and power adaptor.
Do not disconnect the strip from the controller.
If desired, strip extensions (HKT2) can be added here.
The strip can be shortened by cutting along the pre-designated
locations indicated by scissors.
Reset the device by using a paper clip to press the reset button for 10
seconds until the light strip quickly flashes red 3 times. The device will
then restart.
