BELIZE BICYCLE
TRI-RIDER R-3 Recumbent Trike Assembly Guide

PREPARATION

1.
Read this assembly manual BEFORE commencing assembly.
2.
Carefully remove all the components and packaged hardware from the shipping box.
3.
Check the contents of the 2 boxes and confirm that you have received a complete
package.
The contents of the main box should include:
(1)
A main frame assembly
(2)
One 20" left rear wheel assembly
(3)
One 20" right rear wheel assembly
(4)
One 20" front wheel assembly
(5)
Three 20" fenders
(6)
Rear seat support and mesh
(7)
Main seat platform
(8)
Folding basket and mounting hardware
(9)
Bag of hardware containing:
(a)
(b)
(c)
(d)
(e)
(f)
(g)
(h)
(i)
iii.
(j)
(10)
16" Handlebar
The contents of the secondary box should include:
(1)
Rear frame assembly
(2)
Bag with brake callipers, brake rotors and mounting hardware
(3)
Cardboard sleeve with seat mount
(4)
Cardboard sleeve with hardware
i. Support rods for rear seat cage
ii. Mounting hardware and spacers for rear wheels
Brake cables
Gooseneck for handlebar
Fender mounts
Reflectors
Brake levers, V-brake arms and mounting hardware
Pedals (9/16)
Chain and joining link
Quick release clamps and fender mount bottoms
Mounting hardware for rear assembly / main frame
i.
2 bolts
ii.
2 washers
2 locknuts
Grips for handlebars
Revision 2019-04-02
Page 1 of 7
