BELIZE BICYCLE
36/48V BRUSHLESS FRONT HUB MOTOR KIT- BUDDY TRIKE
INSTALLATION & USER MANUAL
Correct installation is critical to prevent the motor from spinning in the fork. Please
review these instructions BEFORE starting the installation and refer to them during
the installation process.
1.
FRONT WHEEL ASSEMBLY ORIENTATION
Refer to photographs (1, 2 and 3)
1.1.
Use a stand to support the trike so that the front fork is off the ground and the
bike is stable during the motor installation process. Place the front wheel / motor
assembly just under the front fork and rotate the axle so that the flats on the axle are
aligned vertically.
1.2.
There is a left and a right side to the motor. The motor cable exits on the right-
hand side. The disc brake mounting interface is on the left-hand side. Installing the
wheel backwards will result in the front wheel spinning the wrong way.
1.3.
The right-hand side of the motor axle is also slotted on one side. This slot
MUST be oriented downwards. This will result in a looped cable near the dropout
and facilitate wheel removal for maintenance or adjustment.
2.
FRONT WHEEL ASSEMBLY SPACING
Refer to photographs (1, 2 and 3)
2.1.
Visually check the fork axle spacing against the motor. In some cases, the fork
will need to be spread to accommodate the inner thrust washers already mounted on
the hub motor axle. These MUST go inside the fork to provide a solid mounting
interface.
2.2.
If the fork needs to be spread, a tool can be easily fabricated using a rear axle,
three axle nuts and washers. Two nuts are used on one side to lock the axle to the
fork and the fork is spread from the other side using the third axle nut. The washers
are used between the fork and the axle nuts to protect the paint.
2.3.
There are several items of required hardware on each side of the hub motor
axle. On the right-hand side there MUST be a thrust washer, a shaped split washer,
a large slotted washer, an axle nut and a rubber end cap. On the left-hand side there
MUST be a thrust washer, a shaped split washer, a torque arm, an axle nut and a
rubber end cap.
P a g e
1 | 10
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Belize Bicycle BUDDY TRIKE
Summary of Contents for Belize Bicycle BUDDY TRIKE
- Page 1 BELIZE BICYCLE 36/48V BRUSHLESS FRONT HUB MOTOR KIT- BUDDY TRIKE INSTALLATION & USER MANUAL Correct installation is critical to prevent the motor from spinning in the fork. Please review these instructions BEFORE starting the installation and refer to them during the installation process.
-
Page 2: Control Box
BELIZE BICYCLE 36/48V BRUSHLESS FRONT HUB MOTOR KIT- BUDDY TRIKE FRONT WHEEL ASSEMBLY INSTALLATION Refer to photographs (1, 2 and 3) 3.1. Install the hub motor assembly with the thrust washers on the axle INSIDE the fork arms and the tabs pointing DOWN. The tabs will line up with the axle opening. - Page 3 A two-piece Pedal Assist assembly is part of the Standard Belize Bicycle Hub Motor Kit. However, it is NOT shipped with the Belize Bicycle Front Hub Motor Kit – Trike to simplify your experience. The Pedal Assist is not compatible with the one piece crank found on your trike so we want to save you the headaches of trying to install something that just won’t fit !!
-
Page 4: Battery Charging And Storage
BELIZE BICYCLE 36/48V BRUSHLESS FRONT HUB MOTOR KIT- BUDDY TRIKE This Belize Bicycle Front Hub Motor Kit – Trike has been shipped with either (1) a track mounted lithium battery that can be bolted to the deck under the rear seat. This involves drilling 4 holes in the frame and using low profile bolts to anchor the battery mounting rail to the deck. - Page 5 BELIZE BICYCLE 36/48V BRUSHLESS FRONT HUB MOTOR KIT- BUDDY TRIKE PHOTO (1) Axle hardware P a g e 5 | 10...
- Page 6 BELIZE BICYCLE 36/48V BRUSHLESS FRONT HUB MOTOR KIT- BUDDY TRIKE PHOTO (2) PHOTO (3) Left hand side axle Right hand side axle P a g e 6 | 10...
- Page 7 BELIZE BICYCLE 36/48V BRUSHLESS FRONT HUB MOTOR KIT- BUDDY TRIKE PHOTO (4) Suggested component locations P a g e 7 | 10...
- Page 8 BELIZE BICYCLE 36/48V BRUSHLESS FRONT HUB MOTOR KIT- BUDDY TRIKE PHOTO (5) Suggested rectangular battery location on floor deck PHOTO (6) Suggested left or right-side rail mounting for fish type battery P a g e 8 | 10...
-
Page 9: Operating Tips
BELIZE BICYCLE 36/48V BRUSHLESS FRONT HUB MOTOR KIT- BUDDY TRIKE PHOTO (7) Twist shifter relocated to left hand side OPERATING TIPS: (A) Both the key in the battery and the key on the throttle must be turned ON for the electric motor to receive power. - Page 10 BELIZE BICYCLE 36/48V BRUSHLESS FRONT HUB MOTOR KIT- BUDDY TRIKE MAINTENAINCE TIPS: When stored outside, use a cover to protect the trike from sun and rain. Prolonged exposure to the sun will fade the paint. Prolonged exposure to rain will cause corrosion.
