Cylindrical Photoelectric Sensor
CY-100 Series
Thank you very much for purchasing Panasonic products.
Please read this Instruction Manual carefully and thor-
oughly for the correct and optimum use of this product.
Kindly keep this manual in a convenient place for quick
reference.
WARNING
Never use this product as a sensing device for per-
sonnel protection.
In case of using sensing devices for personnel pro-
tection, use products which meet laws and standards,
such as OSHA, ANSI or IEC etc., for personnel pro-
tection applicable in each region or country.
1
CE MARKED PRODUCT
This product is CE marked product.
2
CAUTIONS
This product has been developed / produced for in-
dustrial use only.
This sensor is suitable for indoor use only.
Extension up to total 10m (emitter and receiver each
for thru-beam type), or less, is possible with 0.34mm
conductor area, or more, cable.
3
MOUNTING
The tightening torque should be 3N·m or less.
Use a cable with connector &1& & (optional) for
M12 connector type.
Tightening torque for connector part is 2N·m or less.
This product
Mounting board
Nut
Nut
4
RoHS DIRECTIVE
This equipment complies with RoHS (EC and Chinese
directive).
Chinese RoHS indicates inclusion despite regulation
value. (Refer Chinese part.)
