Summary of Contents for Smeg UKM235XNF
- Page 1 Instructions for use Upright freezer...
-
Page 2: Table Of Contents
Thank you for your confi dence in buying our appliance and congratulations on the excellent choice. We hope it will successfully serve its purpose for many years. Upright freezer is used in households for freezing fresh food and storage of frozen food for up to one year (depending on the type of food). -
Page 3: Before Fi Rst Operation
Before fi rst operation • The appliance is manufactured in compliance with all relevant safety standards; however, it is recommended that persons with impaired physical, motional, or mental abilities, or persons with inadequate experience and knowledge, do not use the appliance without due supervision. - Page 4 • Rating plate with basic information is located in the interior of the appliance. If the sticker plate is not suitable for your language, replace it with the attached one. • Warning: Ventilation slots on the appliance or built-in element should always be kept clean and unobstructed.
-
Page 5: Description Of The Appliance
Description of the appliance TRADITIONAL FREEZER Control panel Interior light Freezing compartment Fast freeze for small quantities of food* Large storage compartment - BIG’N’FREEZE DRAWER* Storage compartment Defrost drain outlet groove Legs Wheels* • Interior accessories of the appliance may vary according to the model. •... - Page 6 NO FROST FREEZER Control unit NO FROST freezing unit (cooler, fan ...)* Interior illumination Freezing and storage area Large space - BIG’N’FREEZE drawer* Wheel* • Interior accessories of the appliance may vary according to the model. • Drawers are protected against accidental extraction. To extract the drawer from the appliance, open it and lift front part upwards, then pull it out.
-
Page 7: Installation And Connection
Installation and connection Selecting the location • Place the appliance in dry and well aired room. The appliance operates best at temperature ranges indicated in the chart below. See relevant class of the appliance indicated on the rating plate. Class Ambient temperature SN (subnormal) from +10°C to +32°C... - Page 8 Connecting to power • Use the power cord to connect the appliance to the mains supply power. Wall outlet must be fi tted with ground terminal (safety socket). Nominal voltage and frequency are indicated on the relevant label or rating plate of the appliance. •...
-
Page 9: Reverse Door Swing
Reverse door swing Required tools: socket spanner nr. 8, screwdriver, torx 25 Caution! After unscrewing of before fi xing hinges, hold the door to prevent it from falling and damaging. 1. Remove upper hinge cover (keep it for eventual later use), together with cover on the opposite side of the upper hinge cover (on the opposite side you will insert the attached cover during the assembly), and remove the cover on the opposite... -
Page 10: Control Panel - Appliance With Electronical Regulation
Control panel - appliance with electronical regulation The description refers to the appliance with all available accessories, so that it could contain certain settings our model may not have. CONTROL UNIT I CONTROL UNIT II A Temperature selector and ON/OFF button B Green LED: illuminated when the appliance is in operation C Freezer alarm off button* D Red LED: fl... - Page 11 The ON/OFF button The appliance is switched on by turning the button A towards Max. (Green LED on). The appliance is switched off when the arrow on the button points to the ON/OFF mark (the appliance, however, is still under mains power). Setting freezer •...
- Page 12 The ‘Super Freeze’ • Use this setting after turning on the appliance for the fi rst time, function before cleaning, and when inserting larger quantities of food (see “freezing procedure”). - control unit I : press the E button – The orange LED F lights up.
-
Page 13: Control Panel - Appliance With Mechanical Regulation
Control panel - appliance with mechanical regulation CONTROL UNIT III A Temperature setting knob, on/off, and SF D Red LED – high temperature signal ON/OFF button To activate: rotate the temperature setting knob in the clockwise direction towards the Max position. When the appliance is switched on for the fi... -
Page 14: Freezing And Storage Of Frozen Food
Freezing and storage of frozen food Freezing process • 24 hours before freezing fresh food, activate the Super Freeze function: - control unit I: press the E button; - control units II and III: rotate the A knob to the SF position (Super Freeze). - Page 15 Storing commercially The storage time and recommended temperature for storing frozen food commercially frozen foods is indicated on the packaging. Always follow manufacturer’s instructions for storage and use of frozen food. When shopping be careful to choose only food which is adequately packed and provided with complete data and stored in freezers where the temperature never rises above -18°C.
-
Page 16: Defrosting The Appliance
Defrosting the appliance Defrosting traditional • Clean the freezer when the frost layer in the freezer reaches freezer thickness of around 3-5 mm. • 24 hours prior defrosting activate intensive freezing knob (see section Control of particular models - Intensive freezing), to quickly freeze freshly inserted food. -
Page 17: Cleaning
Cleaning Prior to any cleaning. Please disconnect the appliance from the mains (turn the thermostat button to the position and pull the power cord from the mains outlet). Special antibacterial protection in top layer of inner walls prevents growth of bacteria whilst keeping the interior clean and germ free. -
Page 18: Troubleshooting Guide
Troubleshooting guide Fault: Cause/Remedy The appliance does not operate • Check if there is power in the socket and if the appliance is after connection to the mains: switched on. Cooling system operates • Check air circulation for suffi cient cooling of the compressor, continuously without intermittent and clean the condenser. -
Page 19: Noise Level
Fault: Cause/Remedy Error code displayed (certain • If the character E1 appears on the digital display (certain models only): models only), call service assistance. Troubleshooting helpful hints: • If you are not able to fi x the trouble by any of the above tips, turn the thermostat button to the position ,disconnect the power cord from the mains outlet, wait 10 minutes, and... - Page 20 ZOS 3167, ZOF 2467 FREEZER 142541/en (07-08)
