Quick Set-up Guide
To install of your product, please read this guide manual carefully and completely.
Features
Universal Serial Bus (USB) 2.0 interface for high-speed data transfer.
Buffer Under Run error protection technology
Emergency eject support
Combination of CD-R/RW, DVD-R/RW, DVD+R/RW, DVD+R DL, DVD-R
DL, DVD-RAM and BD-R (SL/DL,LTH)/RE (SL/DL) drive functions into
one drive.
Supports BD 3D Movie Play.
PC USB powered, no AC adapter needed.
Supports LightScribe Direct Label Printing Technology. - *Optional.
*You can use a variety of Drive
BP06LU11
Light Scribe
Package Items
Item
- Slim Portable Blu-ray Writer
- USB 2.0 cable (Y type)
- Software Installation disc
- Quick Guide for Drive
Cautions
System meeting the following requirements is needed in order to use USB
2.0 operation with this drive.
Computer that is equipped with a USB 2.0 – compliant USB connector or PCI
adapter card, and on which the USB 2.0 EHCI (Enhanced Host Controller
Interface) driver software
1)
has been installed.
1)
The USB 2.0 EHCI driver software is supplied with currently available PCI
adapter cards that conform to USB 2.0. Further, Microsoft has released the USB
2.0 EHCI driver software for Windows XP, therefore it is also possible to use this
driver software with Windows XP SP3.
If you want to know in detail, please contact your USB 2.0 adapter dealer or
consult your PC manufacturer, or consult the Microsoft Corporation Web site.

Specifications

Supported Discs
BD-ROM (Single/Dual), BD-R (Single/Dual/LTH),
BD-RE (Single/Dual), DVD-ROM(Single/Dual),
DVD-RW, DVD-R, DVD+RW, DVD+R, DVD+R
Double layer, DVD-R Dual layer, DVD- RAM,
CD-Digital Audio & CD-Extra, CD-Plus, CD-ROM,
CD-ROM XA-Ready, CD-I FMV, CD-TEXT,
CD-Bridge, CD-R, CD-RW, Photo-CD (Single &
Multi-Session), Video CD, DVD-VIDEO, BD-MV
Dimensions
(WxHxD)
156 x 21 x 165 mm
Weight
About 380g
Interface
USB 2.0
Read/Write Speed
Write : BD-R SL: 2x, 4x, 6x
BD-R DL: 2x, 4x, 6x
BD-R LTH: 2x, 4x, 6x
BD-RE (SL/DL): 2x/2x
DVD-R (SL/DL): 2x, 4x, 8x/2x, 4x, 6x
DVD+R (SL/DL): 2.4x, 4x, 8x/2.4x, 4x, 6x
DVD-RW: 1x, 2x, 4x, 6x
DVD+RW: 2.4x, 3.3x , 4x, 8x
DVD-RAM: 2x, 3x, 5x (Ver.2.2)
CD-R: 10x, 16x, 24x
CD-RW: 4x, 10x, 16x, 24x
Read : BD-ROM (SL/DL): 6x/6x max.
BD-R (SL/DL): 6x/6x max.
BD-R LTH: 6x max.
BD-RE (SL/DL): 6x/6x max.
DVD-ROM: 8x max.
DVD-R (SL/DL): 8x/8x max.
DVD+R (SL/DL): 8x/8x max.
DVD-RW: 8x max.
DVD+RW: 8x max.
DVD-RAM (Ver.2.2): 5x max.
CD-R/RW/ROM: 24x max.
CD-DA (Ripping/Audio Play): 24x/10x max.
❋ The drive's appearance and specifications may change without prior notice.
- The maximum data transfer rate varies according to the performance
capabilities of the PC.
- For the sake of periodic improvements, specifications and appearance are
subject to change without notice.
- We have taken all possible measures to assure the quality of our products,
but we cannot be responsible for the consequences if defect occurs.
P/NO. MFL40014155
Ver. A

System Environment

Computer
This unit can be operated in the system environment explained here.
System
requirements
Interface
BP06NU11
Recommended
X
media manufacturer
Quantity
1
1
1
1
* Compatibility problem in write/read function may occur with some media depending on the media
manufacturing quality.
* To achieve maximum Record & Write speed your system may require data to be copied first to the
computer's hard drive rather than directly from another source disc or drive.
Blu-ray Disc movie playback
CPU: Following CPU recommended for playing Blu-ray Disc
-Intel: E6400 or higher
Graphic Card: card with following GPU (Graphic Processing Unit) recommended.
-nVidia: GeForce 7600GT or higher/ GeForce 8400 or higher
-ATI: ATI Radeon HD 2400 or higher
Graphic Card Driver shall meet AACS compliance criteria.
Please consult your graphic card vendor for proper driver solution.
Average Access
Time (
Buffer capacity
MTBF
Power Requirement 5 V DC
Operating Environment
Temperature
Humidity
Storage Environment
Temperature
Humidity
Software
Install the appropriate CD Recording Authoring Software before using this unit.
* Please uninstall any previous CD burning software you may have loaded on
your PC in order to prevent possible compatibility issues.
Once you have installed the application software, you may (if you wish) begin to
reinstall previous software, taking note for errors. We recommend using the drive
with the latest software as some problems encountered when using the drive can
be solved by updating the software.
We recommend to use USBFast Software in Software Installation disc for better
performance.
Please visit www.lgservice.com and install the program,
"LG ODD Online F/W update." By using the program,
you can automatically check the latest information about FirmWares and
update the FirmWare.
Worldwide support ; http://www.LGservice.com
Worldwide corporate site : http://www.LG.com
Slim Portable Blu-ray Writer
• CPU : Pentium D 3.2 GHz or higher (Recommended Core 2
Duo P8600 2.4 GHz or higher.)
• O/S : Windows XP (Home / Professional / Media Center
Edition) with SP3/ Windows Vista (X86, X64)/
Windows 7
• RAM : 1 GB or more
• HDD : 30 GB or more of available space (60 GB for Blu-ray
Disc authoring)
USB 2.0 port
BD-R : LG, Sony, Panasonic, Mitsubishi Kagaku Media,
Verbatim
BD-RE : Mitsubishi Kagaku Media, Maxell, Sony,
Panasonic, Verbatim
DVD-R : Mitsubishi Kagaku Media, Verbatim
DVD-RW : JVC, Mitsubishi Kagaku Media
DVD+R : Mitsubishi Kagaku Media, Verbatim
DVD+RW : Mitsubishi Kagaku Media, Verbatim
DVD±R DL : Mitsubishi Kagaku Media, Verbatim
DVD-RAM : Maxell
CD-R : LG, Mitsubishi Kagaku Media, Verbatim, Taiyo
Yuden, TDK
CD-RW : LG, Mitsubishi Kagaku Media, Verbatim
BD-ROM : 200 ms typ. (Typical)
1 /
Stroke)
DVD-ROM : 160 ms typ. (Typical)
3
DVD-RAM (ver. 2.2) : 180 ms typ. (Typical)
CD-ROM : 160 ms typ. (Typical)
4 MB
60,000 Power On Hours (Duty Cycle 10 %)
5 °C to 40 °C
15 % to 85 %
-30 °C to 60 °C
10 % to 90 % RH
BP06
