Installation
Hardware Installation
Connecting to computer
eSATA
cable
or
USB 2.0 Converter
cable
NOTES
•
Please do not connect the AC adapter and USB 2.0 converter cable by any means
other than specified above.
•
For optimal performance, using the 'USB Booster Program' in the Software CD is
recommended when you connect the USB cable.
•
For optimal performance, using the SATA to eSATA Bracket is recommended when
you connect your old Desktop PC.
NOTES
• Make sure you have a personal
computer with an open USB port or
eSATA port before connecting the drive
to your computer.
• Power for all device should be turn off
before attaching the cables.
Connect the drive to the computer as
shown in figure.
To AC wall
1. Connect the USB converter cable
outlet.
2. Connect the other end of the USB
3. Connect the AC adapter plug to the
4. When the computer is ready, confirm
6
(or eSATA cable) to the External Drive.
converter cable (or eSATA cable) to
your computer.
power connector at the rear of the
drive.
Attach the AC adapter to the AC wall
outlet.
that the drive is detected. And then,
insert the supplied software CD into
the External Drive and install the
software.
