- Page 1 APG3004A Owner’s Manual 1000W 2 STROKE GENERATOR HAVE QUESTIONS PREGUNTAS O DES QUESTIONS OR NEED SERVICE BESOIN D’UNE RÉPARATION NECESITA SERVICIO DO NOT RETURN NE PAS RETOURNER POR FAVOR NO TO STORE AU MAGASIN REGRESE A TIENDA 888.896.6881 888.896.6881 888.896.6881...
-
Page 2: Table Of Contents
1000 WATT GENERATOR Exploded View Safety Information Specifications Components Starting Your Generator Operating Your Generator Stopping Your Generator Maintenance Storage Statement Trouble Shooting... -
Page 3: Exploded View
1000 WATT GENERATOR Exploded View... -
Page 4: Safety Information
1000 WATT GENERATOR Safety Information CAUTION PLEASE READ AND UNDERSTAND THIS MANUAL COMPLETELY, BEFORE OPERATING THIS GENERATOR. Never operate the engine in an enclosed area, All gasoline engines produce carbon monoxide gas while running. Breathing exhaust fumes can kill. Operate the engine in a well-ventilated area, only. -
Page 5: Specifications
1000 WATT GENERATOR Specifications DIMEMSIONS Length 15 in. Width 12 in. Height 14 in. Weight 44.1 Ibs. ENGINE Type Air cooled 2-stroke Fuel Nonleaded gasoline with a minimum of 85% octane Two-stroke lubrication Gasoline and oil mixing ratio 50 : 1 Displacement 63 cc Starting System... -
Page 6: Components
1000 WATT GENERATOR Generator Components 1. Handle 2. Fuel Cap 3. Fuel Tank 4. Fuel Shut-off 5. Recoil Starter 6. Engine On-Off Switch 7. Throttle Lever 8. Air Cleaner 9. Control Panel 10. Generator 11. Muffler 12. Cylinder 13. Spark Plug 11 11... -
Page 7: Starting Your Generator
1000 WATT GENERATOR STARTING THE ENGINE 1. Disconnect all electric appliances from generator before starting. 2. Turn fuel shut-off lever to "ON". 3. Move Choke lever all the way to the left. 4. Turn engine switch to "ON" position. 5. Pull recoil starter cord slowly until engaged, then pull briskly to start. 6. -
Page 8: Storage
1000 WATT GENERATOR Clean fuel filter every 150 hours of run time. 1. Remove fuel filter from inside fuel tank. 2. Clean with solvent. 3. Wipe dry. 4. Insert filter back in fuel tank. STORAGE If the generator will not be used for more than one month, follow the following procedures: 1. -
Page 9: Trouble Shooting
1000 WATT GENERATOR... - Page 10 1000 WATT GENERATOR G E N E R AT O R T H E O R Y D IA G R A M G E N E R AT O R T H E O R Y D IA G R A M Stator Stator Rotor...
