- Page 1 Installation and Operation Manual CHURRASCO 900 Specialty Grill Gas-Fired Grill CHURRASCO WS-LCHUG-900 WOOD STONE CORPORATION Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 www.woodstone-corp.com DOC NO M0100.02 REVISED June 2015...
-
Page 2: Table Of Contents
WIRE DIAGRAM � � � � � � � � � � � � � � � � � � � � 15 LIMITED WARRANTY � � � � � � � � � � � � � � � � 16 Wood Stone Corporation Toll Free 800.988.8103 1801 W. -
Page 3: Churrasco
CASCADE ROTISSERIE CHURRASCO Churrasco–900 Installation and Operation Manual INSTALLATION AND OPERATION MANUAL FOR THE WOOD STONE CHURRASCO GRILL SPECIALITY COOKING EQUIPMENT WS-LCHUG-900-(NG, LP) GAS-FIRED CHURRASCO ADDITIONAL COPIES AVAILABLE UPON REQUEST Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. -
Page 4: Cautions And Warnings
Installation and Operation Manual INSTALLATION AND OPERATING INSTRUCTIONS FOR THE WS-LCHUG-900 WOOD STONE GAS-FIRED CHURRASCO RETAIN THIS MANUAL FOR FUTURE REFERENCE Additional copies of this manual available on woodstone-corp�com� For prompt responses to service/maintenance questions, call us at @ 1-800-988-8103�... - Page 5 This equipment has been tested and approved by Intertek Testing Services, and is ETL Listed to ANSI Z83.11b - 2009, CSA 1.8b-2009 and to NSF/ANSI Standard 4 - 2009. Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166...
-
Page 6: Specifications
ONS ARE IN INCHES DIMENSIONS ARE IN INCHES UNLESS NOTED OTHERWISE ANY REPRODUCTION OR USE IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS PROHIBITED AR ±1/2 [±10mm], ANGULAR ±2° TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°... -
Page 7: Receiving & Assembly
Maximum capacity per spit: 6�5 lbs Churrasco with 11 Spit seated in Spits in position Spit Rail Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... -
Page 8: Clearances & Venting
VENTING The Wood Stone Circular Grill must be vented using a Listed Type 1 exhaust hood or one constructed in accordance with the Standard for Ventilation Control and Fire Protection of Commercial Cooking Operations, NFPA 96, and all relevant local and national codes, and in a manner acceptable to the authority having jurisdiction�... -
Page 9: Utility Information
The appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve (supplied by others) during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (3.5 kPa). Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. - Page 10 DO NOT USE A FLAME TO TEST FOR LEAKS! Wood Stone recommends that a manual, individual appliance shutoff valve be supplied, located between the grill and the main gas supply, and be left readily accessible� MANIFOLD PRESSURE / GAS RATING This appliance is equipped with a gas pressure regulator suitable for incoming pressure of up to 1/2 psi (14"...
-
Page 11: Lighting Instructions
Pilot View port, then release the IGNITION button� 3. Turn Pilot Knob to the ON position� ON position Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... -
Page 12: Daily Operation
Alternatively, these items can be cleaned in a dishwasher� For built-up debris, oven cleaner may be required� EXHAUST HOOD Refer to the exhaust hood manufacturer’s recommendations for inspection, maintenance and cleaning� Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166... -
Page 13: Maintenance
2. Unscrew the Ignitor button to access the AA battery� 3. Replace battery, placing negative (-) end into spring on button, sliding positive (+) end into receptacle� 4. Tighten Ignitor button� Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166... -
Page 14: Troubleshooting
• Cracked burner head Replace burner Please contact Wood Stone at 1-800-988-8103 should service be necessary, or if you have any questions about your appliance. Our service hours are 8am to 4:30pm Pacific Standard Time. Follow the recorded instructions for Emergency Service if you require assistance during non-business hours. -
Page 15: Wire Diagram
220 VAC DIAG #: WD803 Rev. 0 Bellingham, WA +1(360)650-1111 www.woodstone-corp.com DATE: 1/30/2014 Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... -
Page 16: Limited Warranty
LIMITATIONS OF LIABILITY In the event of warranty claim or otherwise, the sole obligation of Wood Stone shall be the repair and/or replacement, at the option of Wood Stone, of the appliance or component or part thereof� Such repair or replacement shall be at the expense of Wood Stone with the exception of travel over 100 miles or two hours, overtime, and holiday charges which shall be at the expense of the purchaser�...
