Installation and
Operation Manual
ELECTRIC PLANCHA
Speciality Equipment
Electric Countertop Models
ELECTRIC PLANCHA WS-PL-MTL-40-35-4-CT
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
www.woodstone-corp.com
Toll Free 800.988.8103
Tel 360.650.1111
Fax 360.650.1166
DOC NO M0061.03
REVISED July 2015
Advertisement
Table of Contents
Related Manuals for Wood Stone WS-PL-MTL-40-35-4-CT
Summary of Contents for Wood Stone WS-PL-MTL-40-35-4-CT
- Page 1 Installation and Operation Manual ELECTRIC PLANCHA Speciality Equipment Electric Countertop Models ELECTRIC PLANCHA WS-PL-MTL-40-35-4-CT WOOD STONE CORPORATION Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 www.woodstone-corp.com DOC NO M0061.03 REVISED July 2015...
-
Page 2: Table Of Contents
LIMITED WARRANTY � � � � � � � � � � � � � � � � � 15 Wood Stone's electric Plancha has been tested and approved by Intertek, and is ETL listed to UL 197 and CSA C22.2 No. 109-M1981 and to NSF/ANSI Standard 4 - 2009. -
Page 3: Cautions And Warnings
CAUTIONS AND WARNINGS Electric Metal Countertop Plancha Installation and Operation Manual INSTALLATION AND OPERATION MANUAL FOR THE WOOD STONE ELECTRIC PLANCHA GRILL STONE-FIRED COOKING EQUIPMENT WS-PL-MTL-40-35,-4-CT 4-ZONE METAL COUNTERTOP MODELS ADDITIONAL COPIES AVAILABLE UPON REQUEST RETAIN THIS MANUAL FOR FUTURE REFERENCE Additional copies of this manual at woodstone-corp�com�... -
Page 4: Specifications
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION ANY REPRODUCTION OR USE IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS PROHIBITED THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION... -
Page 5: Venting And Clearances
Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com specifications without notice. WS-PL-MTL-40-35-4-CT. Revised July 2015. Doc no: M0061.03... -
Page 6: Basic Operation
Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com specifications without notice. WS-PL-MTL-40-35-4-CT. Revised July 2015. Doc no: M0061.03... -
Page 7: Daily Use And Maintenance
CAUTION: COOK SURFACE IS VERY HOT! 3. End of the day: The Plancha cook surface should be cleaned thoroughly at the end of each day� Wood Stone recommends the 3M 710 Scotch Brite Quick Clean Griddle Cleaning System for cleaning the Plancha cooking surface�... -
Page 8: Troubleshooting
Wood Stone Service Department at 1-800-988-8103. Our service hours are 8 am to 4:30 pm Pacific Time. Follow the recorded instructions for Emergency Service if you require assistance during non-business hours. A Wood Stone technician will promptly respond to your call. Wood Stone Corporation Toll Free 800.988.8103... -
Page 9: Phase Electrical Diagrams
1 PHASE ELECTRICAL DIAGRAMS Electric Metal Countertop Plancha Installation and Operation Manual 4-ZONE 208/240 VAC 1 PHASE NOTE: MUST be connected ONLY to the voltage specified on the equipment data plate�... - Page 10 1 PHASE ELECTRICAL DIAGRAMS Electric Metal Countertop Plancha Installation and Operation Manual 4-ZONE 208/240 VAC 1 PHASE NOTE: MUST be connected ONLY to the voltage specified on the equipment data plate�...
- Page 11 1 PHASE ELECTRICAL DIAGRAMS Electric Metal Countertop Plancha Installation and Operation Manual 4-ZONE 208/240 VAC 1 PHASE NOTE: MUST be connected ONLY to the voltage specified on the equipment data plate�...
-
Page 12: Phase Electrical Diagrams
3 PHASE ELECTRICAL DIAGRAMS Electric Metal Countertop Plancha Installation and Operation Manual 4-ZONE 208/240 VAC 3 PHASE NOTE: MUST be connected ONLY to the voltage specified on the equipment data plate�... - Page 13 3 PHASE ELECTRICAL DIAGRAMS Electric Metal Countertop Plancha Installation and Operation Manual 4-ZONE 208/240 VAC 3 PHASE NOTE: MUST be connected ONLY to the voltage specified on the equipment data plate�...
- Page 14 3 PHASE ELECTRICAL DIAGRAMS Electric Metal Countertop Plancha Installation and Operation Manual 4-ZONE 208/240 VAC 3 PHASE NOTE: MUST be connected ONLY to the voltage specified on the equipment data plate�...
-
Page 15: Limited Warranty
LIMITATIONS OF LIABILITY In the event of warranty claim or otherwise, the sole obligation of Wood Stone shall be the repair and/or replacement, at the option of Wood Stone, of the appliance or component or part thereof� Such repair or replacement shall be at the expense of Wood Stone with the exception of travel over 100 miles or two hours, overtime, and holiday charges which shall be at the expense of the purchaser�...
