OPERATION
MANUAL
HVS-GPIO128
Interface Extension Unit
st
1
Edition

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HVS-GPIO128 and is the answer not in the manual?

Questions and answers

Related Manuals for FOR-A HVS-GPIO128

Summary of Contents for FOR-A HVS-GPIO128

  • Page 1 OPERATION MANUAL HVS-GPIO128 Interface Extension Unit Edition...
  • Page 2 Precautions Important Safety Warnings [Power] Operate unit only at the specified supply voltage. Caution Disconnect the power cord via the power plug only. Do not pull on the cable portion. Do not place or drop heavy or sharp-edged objects on the power cord. A damaged cord can cause fire or electrical shock hazards.
  • Page 3 [Circuitry Access] Do not remove covers, panels, casing, or access the circuitry with power applied to the unit. Turn the power off and disconnect the power cord prior to removal. Internal servicing / adjustment of unit should only be performed by qualified personnel. Do not touch any parts / circuitry with a high heat factor.
  • Page 4 AC adapter For power redundancy. ◆ Items needed to be prepared ITEM REMARKS For HVS-GPIO128 and switcher connection LAN cable UTP Category 5e or 6 (straight-through) Computer For network settings for HVS-GPIO128 For network settings for HVS-GPIO128 (See Sec. 4. “Setup Menu.“)

  • Page 5: Table Of Contents

    4. Setup Menu ............................13 4-1. If Connecting via LAN ......................13 4-2. If Connecting via RS-232C ...................... 13 4-3. Changing HVS-GPIO128 IP Address ..................14 4-4. Resetting the Setup Menu......................15 5. Specifications and Dimensions ......................16 5-1. Unit Specifications ........................16...

  • Page 6: Hvs-Gpio128 Overview

    1. HVS-GPIO128 Overview The HVS-GPIO128 is a Interface Extension Unit for HVS (Hanabi) Series switchers. Supported HVS Series switcher Number of unit connection HVS-2000 An HVS-GPIO128 unit can add the following interfaces to switchers.  Serial port: 9-pin D-sub x 4 ...

  • Page 7: Rear Panel

    2-2. Rear Panel SER VICE SERIAL RATING LABEL 2 - DC12V IN -1 GPI 1 GPI 2 GPI 3 GPI 4 Name Description For switcher (MU) connection via LAN Ethernet (10/100BASE-TX） SERVICE For service use (Setup menu settings by serial connection) DC12V IN 1 For 12 VDC power input DC12V IN 2...

  • Page 8: Interfaces

    2-3. Interfaces 2-3-1. GPI 1-4 ◆ Connector Appearance 37-pin D-sub x 4 ports Total of 128 GPI connections are provided by 4 ports. (32 x 4) Both GPI input and output signals can be assigned to each connection (pin). Assignments can be changed in the switcher menu.
  • Page 9 ◆ GPI IN circuit Switch or Relay Open Collector Ext. device HVS-GPIO128 Ext. device HVS-GPIO128 ◆ GPI OUT / TALLY OUT circuit HVS-GPIO128 Ext. device Max. 40V Max. 100mA 10Ω * About 0.9 V when ON...

  • Page 10: Serial1-4

    2-3-2. SERIAL1-4 ◆ Connector Appearance 9-pin D-sub (male) x 4 ports ◆ RS-232C / RS-422 Specifications Select RS-232C or RS-422 using switches on the card. (Default: RS-232C) ► See Sec. 2-4. “Internal Settings.” RS-232C Pin Assignments RS-422 Pin Assignments Pin No. Signal Description Pin No.

  • Page 11: Internal Settings

    CAUTION equipment. Remove two screws on both sides of the HVS-GPIO128 chassis and open the top cover plate. The board as shown below will appear. As factory default, switches on the board are set as shown below. (■ indicates switch position.)

  • Page 12: Connecting To The Hvs Switcher

    Setup menu to the current ones. (2) Connect HVS-GPIO128 to the HVS Series switcher (MU) via LAN. Use a LAN switch to connect HVS-GPIO128 to LAN 1(MAIN) on the switcher. (3) Connect HVS-GPIO128 to serial control devices.

  • Page 13: Setup Menu

    4. Setup Menu Network settings such as IP address setting can be changed in the Setup menu. Prepare a PC to connect to the HVS-GPIO128 via LAN or RS-232C. Use a terminal software (such as Tera Term) to communicate with HVS-GPIO128.

  • Page 14: Changing Hvs-Gpio128 Ip Address

    (7) Change other settings, as needed, in the same manner. (8) After all settings are complete, type “6”, then press Enter. HVS-GPIO128 will automatically restart and changes are applied. To close the Setup menu without changing settings, type “7”, then press Enter.

  • Page 15: Resetting The Setup Menu

    4-4. Resetting the Setup Menu To reset settings to factory default, use an internal switch on the HVS-GPIO128. Proceed as follows. (1) Power off the HVS-GPIO128. (2) Unsecure two screws on both sides to remove the top plate. (3) Turn on Dipswitch S4-4. (See Sec. 2-4. “Internal Settings.”) (4) Power on the HVS-GPIO128.

  • Page 16: Specifications And Dimensions

    100V to 120V AC, 8 VA (4 W) 200V to 240V AC, 13 VA (6 W) Dimensions 430(W) x 44(H) x 110 (D) mm EIA1RU 480(W) (W/ rack mount brackets) Weight 1.6 kg HVS-GPIO128 GPI UNIT SERIAL POWER LAN RESET 5-2. External Dimensions (All dimensions in mm)
  • Page 17 Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
  • Page 18 Tel: +1 352-371-1505 Fax: +1 714-894-5399 FOR-A Latin America and the Caribbean Miami Office Tel: +1 657-600-5759 FOR-A Latin America and the Caribbean Sao Paulo Office Tel: +55 (0)11-99913-3751 FOR-A Europe S.r.l. Via Volturno, 37, 20861 Brugherio MB, Italy Tel: +39 039-916-4811...
