- Page 1 INSTALLATION GUIDE HVS-100AO HD/SD Analog Output Card HVS-100DO HD/SD Digital Output Card HVS-100PCO PC Output Card Edition - Rev.1...
-
Page 2: Prior To Starting
Prior to Starting HVS-100AO, HVS-100DO, and HVS-100PCO are output expansion cards for HVS-100, HVS-2000 and HVS-490 units. HVS-100DO and HVS-100PCO are output expansion cards for VRP-100 units. Check to ensure no damage has occurred during shipment. If damage has occurred, or items are missing, inform your supplier immediately. - Page 3 AC100-240V 50/60Hz IN HVS-2000 The HVS-100AO, HVS-100DO, and/or HVS-100PCO cards can be installed into I/O A and I/O B from the HVS-2000 rear panel. Note that the I/O A and I/O B can accept both input and output cards.
-
Page 4: Checking The Installation
1-2. Inserting a Card into a Slot (1) Turn off the power of your Main Unit and disconnect the power cord(s). (2) Remove the two screws securing the blank panel of Slot B or C and remove the blank panel. (3) Position the output card between the guide rails of the slot and insert the card into the slot. -
Page 5: Output Channels
2. Output Channels Each card provides two channels of output and each channel can be independently set. HVS-100 Each option channel should be set up in the [SETUP – OUTPUT－OPTION] menu. Additional output channels on SLOT-B are called B-Ch1 and B-Ch2. Additional output channels on SLOT-C are called C-Ch1 and C-Ch2. - Page 6 2 Executive Drive, Suite 670, Fort Lee Executive Park, Fort Lee, NJ 07024, USA Tel: +1 201 944 1120 Fax: +1 201 944 1132 FOR-A Corporation of America Distribution & Service Center 2400 N.E. Waldo Road, Gainesville, FL 32609, USA Tel: +1 352 371 1505...
