  • Page 1 INSTALLATION GUIDE HVS-2000-2SI-associated Fan Unit Replacement Edition...
  • Page 2 Upon Receipt HVS-2000-2SI is a software option that allows you to use 4K-2SI mode in the HVS-2000. If HVS-200-2SI software is installed in the HVS-2000, the fan units need to be replaced. (Fan units are included with HVS-2000-2SI software.) This installation guide explains how to replace front and rear fan units in an HVS-2000.
  • Page 3 1. Replacing Fan Units  Replace the Front Fan Unit (1) Release the two screws on both sides securing the front panel to remove the panel. HVS-2000 DIGITAL VIDEO SWITCHER POWER 1 ALARM POWER 2 ALARM Screw Screw POWER 3 ALARM (2) Remove the two screws on the left, front fan unit.
  • Page 4  Replace the rear fan unit (1) Remove the four screws on the right, rear fan unit. (2) Hold and pull the fan unit handle out. Screws SER. NO. A UX SDI OUTPUT RS-422 LAN1 LAN2 Handle GENLOCK GPI IN TALLY OUT ARCNET RE F IN...
  • Page 6 2 Executive Drive, Suite 670, Fort Lee Executive Park, Fort Lee, NJ 07024, USA Tel: +1 201 944 1120 Fax: +1 201 944 1132 FOR-A Corporation of America Distribution & Service Center 2400 N.E. Waldo Road, Gainesville, FL 32609, USA Tel: +1 352 371 1505...
