- Page 1 OPERATION MANUAL HVS-AUX16A HVS-AUX16B HVS-AUX32A HVS-AUX64A Auxiliary Unit Edition...
- Page 2 Edition Revision History Edit. Rev. Date Description Section/Page 2014/05/19 2014/06/06 Supported HVS-390HS 2015/04/14 Supported HVS-2000 Sec. 3-3 Changed model names (HVS-XT100/110 >> HVS-100/110) 2015/07/27 Added HVS-AUX16B. 2018/07/27 Supported HVS-490 and HVS-1200...
- Page 3 Precautions Important Safety Warnings [Power] Operate unit only at the specified supply voltage. Caution Disconnect the power cord via the power plug only. Do not pull on the cable portion. Do not place or drop heavy or sharp-edged objects on the power cord. A damaged cord can cause fire or electrical shock hazards.
- Page 4 [Circuitry Access] Do not remove covers, panels, casing, or access the circuitry with power applied to the unit. Turn the power off and disconnect the power cord prior to removal. Internal servicing / adjustment of unit should only be performed by qualified personnel. Do not touch any parts / circuitry with a high heat factor.
- Page 5 Upon Receipt Unpacking HVS-AUX16A, HVS-AUX16B, HVS-AUX32A and HVS-AUX64A units and their accessories are fully inspected and adjusted prior to shipment. Operation can be performed immediately upon completing all required connections and operational settings. Check your received items against the packing lists below. Check to ensure no damage has occurred during shipment.
-
Page 6: Table Of Contents
4-3-1. Changing the AUX Unit IP Address ...................15 4-3-2. Changing the AUX ID Number ...................16 4-4. LOCK (Front Panel Lock) ......................16 5. Specifications and Dimensions ......................17 5-1. Unit Specifications ........................17 5-2. External Dimensions .........................17 5-2-1. HVS-AUX16A........................17 5-2-2. HVS-AUX16B........................18 5-2-3. HVS-AUX32A........................18 5-2-4. HVS-AUX64A........................19... -
Page 7: Prior To Starting
FOR-A representative. We will do our best to be of continuing service to you. 1-2. Features Auxiliary Units, HVS-AUX16A, HVS-AUX16B, HVS-AUX32A and HVS-AUX64A (hereafter called AUX unit), are designed to remotely control M/E (PGM/PST) and auxiliary outputs of the Hanabi series switchers and Multiviewers. -
Page 8: Panel Descriptions
HVS-AUX16A HVS-AUX16A AUXILIARY UNIT LOCK POWER NET MASK AUX IP SW IP AUX ID OCTET BUSY SETUP SHIFT/TAKE LOCK RESET HVS-AUX16B HVS-AUX16B AUXILIARY UNIT POWER AUX IP NET MASK SW IP AUX ID OCTET LOCK BUSY LOCK SETUP... - Page 9 Displays the LOCK status. See the table on the next page for details on indications. LOCK See section 4-4. "LOCK (Front Panel Lock)" for details on the lock function. Used to set IP address or other settings. SETUP See section 4-1 "SETUP Menu" for SETUP menu details. RESET Used to re-initialize the AUX Unit.
-
Page 10: Rear Panel
2-2. Rear Panel HVS-AUX16A/32A/64A DC12V IN DC12V IN HVS-AUX16B DC12V IN Letter Name Description For switcher connection Ethernet port (100BASE-TX, RJ-45) DC12V IN 12 V DC power inlet... -
Page 11: Connection
3. Connection The example systems shown below are for switchers HVS-100, HVS-390HS and HVS-2000. Refer to each switcher operation manual for connections other than these switchers. 3-1. Connecting HVS-100/110 Reference PGM(AUX1) Preview (AUX2) Video server, VTR, etc. HD/SD SDI Multiview (HDMI) HD/SD SDI TSG (REF) -
Page 12: Connecting Hvs-390Hs
3-2. Connecting HVS-390HS HVS-AUX16A rear panel DC12V IN To AC adapter LAN cable (straight) TSG (Reference) Video Server HD/SD SDI VTR, etc. 75Ω termination HVS-390HS rear panel SDI INPUT GENLOCK REF IN REF OUT SDI OUTPUT HDMI GPI IN GPI/TALLY OUT TO OU RATING LABEL EDITOR... -
Page 13: Connecting Hvs-2000
3-3. Connecting HVS-2000 REF signal HD/SD SDI (M/E1 PGM) HVS-2000 HD/SD SDI (M/E2 PGM) rear panel 75Ω termination SER. NO. M /E A UX AC power SDI OUTPUT source RS-422 LAN1 LAN2 GENLOCK GPI IN TALLY OUT ARCNET RE F IN REF OUT (MA IN) (SU B) -
Page 14: Setup (Network Settings)
4. Setup (Network Settings) Network settings should be changed for multiple AUX units connected to a switcher, since identical IP addresses within a network are not allowed. 4-1. SETUP Menu The SETUP button allows you to enter Setup Menu mode, in which AUX Unit network settings can be displayed and changed. -
Page 15: Connecting Two Or More Aux Units To A Switcher
4-3. Connecting Two or More AUX Units to a Switcher Connection Example 192.168.0.10 192.168.0.20 Straight-through cable AUX ID: 1 REF IN REF OUT TO OU GENLOCK SDI INPUT HDMI OUT RS-422 GPI IN/TALLY OUT AC100-240V 50/60Hz IN AC100-240V 50/60Hz IN HVS-AUX16A (1) rear panel HVS-100 rear panel 192.168.0.21... -
Page 16: Changing The Aux Id Number
(7) To verify the change, press SETUP, AUX IP, and then 8 . Check whether Buttons 9 to 16 show number “21” in binary mode. Use the same procedure to change NETMASK, SW IP or DEFAULT GATEWAY, as necessary. 4-3-2. Changing the AUX ID Number (1) Press SETUP. -
Page 17: Specifications And Dimensions
5. Specifications and Dimensions 5-1. Unit Specifications AUX16A AUX32A AUX64A AUX16B Free Buttons LOCK button Available Available Available Available SHIFT/TAKE button Available Available TAKE only Available Interface (LAN) 100BASE-TX RJ-45 x 1 (For switcher connection. Hub required for multiple units connection) Temperature 0ºC to 40ºC Humidity... -
Page 18: Hvs-Aux16B
5-2-2. HVS-AUX16B (All dimensions in mm.) HVS-AUX16B AUXILIARY UNIT POWER AUX IP NET MASK SW IP AUX ID OCTET LOCK BUSY LOCK SETUP RESET SHIFT/TAKE 5-2-3. HVS-AUX32A (All dimensions in mm.) AUX IP NET MASK SW IP AUX ID OCTET... -
Page 19: Hvs-Aux64A
5-2-4. HVS-AUX64A (All dimensions in mm.) HVS-AUX64A AUXILIARY UNIT AUX IP NET MASK SW IP AUX ID OCTET POWER LOCK BUSY TAKE LOCK SETUP RESET... - Page 21 Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
- Page 22 2018/07/23 Printed in Japan FOR-A COMPANY LIMITED Head Office 3-8-1 Ebisu, Shibuya-ku, Tokyo 150-0013, Japan Overseas Division Tel: +81(0)3 3446 3936 Fax: +81(0)3 3445 5116 Japan Branch Offices Osaka/Okinawa/Fukuoka/Hiroshima/Nagoya/Sendai/Sapporo R&D/Production Sakura Center/Sapporo Center FOR-A Corporation of America 11155 Knott Ave., Suite G&H, Cypress, CA 90630, USA. Tel: +1 714 894 3311 Fax: +1 714 894 5399 FOR-A Corporation of America East Coast Office...
