Power Transformer - Infinity Reference Series Service Manual

RS-8/RS-8a
All manuals and user guides at all-guides.com

Power Transformer

3.080
2.650
2.600
R0.188
(2X)
INPUT 115 V @ 60 HZ
OUTPUT
NO LOAD 33.3 V CT (SEC 1)
NOMINAL 33.3 V CT (SEC 2)
WITH LOAD 30.12 V CT @ 2.0 Amps. (SEC 1)
30.12 V CT @ 2.0 Amps. (SEC 2)
PRI 5.06 Ohms MAX
SEC1 1.0 Ohms MAX
SEC2 1.0 Ohms MAX
3
115V
5
1.330
TERMINAL FASTON (3X)
0.187" X 0.020"
RED COLOR WITH
YELLOW STRIPE AROUND
RED COLOR (2X)
3.570
11.00
WIRE LENGTH
(INCLUDES TERMINAL)
RED
34V @ 2A
CENTER TAP TO
BE RED WIRE WITH
YELLOW STRIPE
34V @ 2A
RED
18
AMP 2-520263-2 (3X)
OR EQUIVALENT
(MATES WITH FASTON
TERMINAL 0.250" X 0.032")
