Installation
Line Guide Kits
LineLazer™
3500, 5000, 3900, 5900 & 200HS
– For application of line striping materials –
3300 psi (228 bar, 22.8 MPa) Maximum Working Pressure
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
Model 277062, Series A
Short, for parking lot striping and road striping
Model 277063, Series A
Long, for road striping only
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
Copyright 2005, Graco Inc. is registered to I.S. EN ISO 9001
311067B
ti6542b
Advertisement
Related Manuals for Graco LineLazer 3500
Summary of Contents for Graco LineLazer 3500
- Page 1 Model 277062, Series A Short, for parking lot striping and road striping Model 277063, Series A Long, for road striping only ti6542b GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441 Copyright 2005, Graco Inc. is registered to I.S. EN ISO 9001...
- Page 2 1.0 in. NOTE: Steps 3 and 4 apply to all LineLazers. A = 6.55 in. — LineLazer 3500 & 5000 (must be drilled) 3. Locate brackets on frame so bracket holes align with frame holes and bracket flanges rest on top of A = 5.55 in.
- Page 3 Parts Drawing / List Line Guide Model 277062, Series A Short, for parking lot striping and road striping Line Guide Model 277063, Series A Long, for road striping only No. Part No. Description 15F348 . ROD (used on 277062) 15F350 .
- Page 4 All written and visual data contained in this document reflects the latest product information available at the time of publication. Graco reserves the right to make changes at any time without notice. Graco Headquarters: Minneapolis International Offices: Belgium, Korea, China, Japan GRACO INC.
