Step 2: Connecting the speaker

The connector of the speaker cords and the color tube are color-coded depending on the type of speaker.
Connect the speaker cords to match the color of the SPEAKER jacks.
Connect the connector for the remote control to the REMOTE CTRL jack.
Green
White
Note
• You can use the remote by pointing it toward either the speaker or the subwoofer when the connector for the remote
is inserted into the REMOTE CTRL jack. When the connector for the remote is not connected, the speaker does not
receive signals from the remote.
Rear of the
subwoofer
ONLY FOR SS-CT500
L
CENTER
R
SPEAKER
Red
A
Speaker
A Speaker cord (supplied)
FM
EZW-T100 75 COAXIAL
BD IN DVD IN SAT/CATV IN TV OUT
OPTICAL
TV IN VIDEO 2 IN VIDEO 3 IN
DIGITAL
VIDEO IN COMPONENT VIDEO IN
ASSIGNABLE
L L
DC 5V ONLY FOR
0.7A MAX SS-CT500
R R
AUDIO IN AUDIO IN
REMOTE
DMPORT TV VIDEO 1 VIDEO 2 VIDEO 3
CTRL
Connector for the
remote control
AM
ANTENNA
HDMI
COAXIAL
VIDEO 3 IN
Y
P /
B
C
B
P /
R
C
R
continued
25
