ASSEMBLY INSTRUCTIONS
MARANA LOW STORAGE CABINET
MODEL # AXCCMAR14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MARANA AXCCMAR14 and is the answer not in the manual?

Questions and answers

Summary of Contents for Cypress Hills MARANA AXCCMAR14

  • Page 1 ASSEMBLY INSTRUCTIONS MARANA LOW STORAGE CABINET MODEL # AXCCMAR14...
  • Page 2 DO NOT RETURN FOR REPLACEMENT PARTS OR OTHER INQUIRIES PLEASE CONTACT US AT: 1-800-667-8992 PLEASE ENSURE TO HAVE THE COLLECTION NAME AND DESCRIPTION FROM THE PACKAGING OR INSTRUCTION BOOKLET...
  • Page 3: Safety Information

    IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION CAUTION: Injuries and damage can occur from furniture tip over if product is not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided with the product.
  • Page 4: Care And Maintenance

    IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. CARE and MAINTENANCE Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks.
  • Page 5: Pre-Assembly Information

    PRE-ASSEMBLY INFORMATION MODEL # AXCCMAR14 PART DESCRIPTION LEFT SIDE RIGHT SIDE QTY 1 QTY 1 QTY 1 BOTTOM SHELF DIVIDER CABINET SHELF QTY 1 QTY 1 QTY 2 Warning Label LEFT DOOR RIGHT DOOR LEFT BACK PANEL RIGHT BACK PANEL QTY 1 QTY 1 QTY 1...
  • Page 6: Hardware Description

    PRE-ASSEMBLY INFORMATION MODEL # AXCCMAR14 HARDWARE DESCRIPTION WOOD DOWEL CAM LOCK PIN ALLEN KEY SCREW CAM LOCK M6 X 30mm QTY 9 SETS QTY 9 QTY 6 PHILLIPS SCREW ROUND HEAD ALLEN KEY SHELF SUPPORT M4 X 15mm QTY 1 QTY 12 QTY 18 HANDLE...
  • Page 7 COMPONENTS-KEY DIAGRAM MODEL # AXCCMAR14...
  • Page 8 ASSEMBLY MODEL # AXCCMAR14 STEP-1 1. Insert 2 Dowels 3 into guide holes on Divider C . 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of Dowels should be exposed. 3. Attach Divider C to Bottom Shelf D using 3 Allen Key Screws 1 . 4.
  • Page 9 ASSEMBLY MODEL # AXCCMAR14 STEP-2 1. Insert 4 Dowels 3 into guide holes on Bottom Shelf D ( 2 dowels on each side). 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of Dowels should be exposed. 3.
  • Page 10 ASSEMBLY MODEL # AXCCMAR14 STEP-3 1. Attach 3 Cam Lock Pins 2 to middle Top A using pre-drilled holes. 2. Align Cam Lock Pins with guide holes on Divider C . 3. Insert 3 Cam Locks 2 into guide holes on Divider C . 4.
  • Page 11 ASSEMBLY MODEL # AXCCMAR14 STEP-4 Triangle ruler NOTE: The triangle ruler is not included in the hardware pack. Adjust the cabinet frame before assembling the back panels. STEP-5 Note: Warning Label 1. Attach Back Panels GL , GR to back frame of Storage using 18 Phillips Screws Round Head 5 through guide holes.
  • Page 12 ASSEMBLY MODEL # AXCCMAR14 STEP-6 1. Attach Adjustable Hinges 11 to Doors FL , FR using Phillips Screws 10 into pre-drilled holes on Doors FL , FR . 2. Use Phillips screwdriver to attach Handle 7 to Doors FL , FR . STEP-7 1.
  • Page 13: Important Note

    ASSEMBLY MODEL # AXCCMAR14 STEP-8 IMPORTANT NOTE: Tighten the Screw marked II to fasten hinge. The door may need to be adjusted so that all the spaces between the door and the unit sides are equal. To adjust, follow instructions: 1.
  • Page 14 ASSEMBLY MODEL # AXCCMAR14 STEP-9...
  • Page 15 ASSEMBLY MODEL # AXCCMAR14 STEP-10 shelf support anti - tipping shelf level 1 shelf level 2 shelf level 3 1. Use 4 Shelf Supports 6 for each Cabinet Shelf E in desired location. 2. 2 Shelf Supports 6 may be used on back top of each Cabinet Shelf E as a tipping restraint.
  • Page 16 FURNITURE TIP OVER RESTRAINT ASSEMBLY WARNING Serious or fatal crushing injuries can occur from furniture tip-over. If the furniture tip over restraint kit is not in the box, please contact our customer service department in order to obtain another kit before using the furniture. STEP-11 NOTE: The screwdriver is not included in the hardware pack.
  • Page 17 FURNITURE TIP OVER RESTRAINT ASSEMBLY Furniture Tip Over Restraint Instructions: Attach one of the mounting brackets securely to the back edge of the furniture. Use the shorter screw. Determine where furniture is to be placed and mark location on the wall for mounting bracket screw hole approximately 2 inches below the bracket mounted to the furniture.
