Page 1 of 6
Minimum No.
Of People
Recommended
To Assemble
This Product :
Approximate
Assembly
Time :
MINUTES
BEFORE YOU
START, HERE
IS SOME
HELPFUL
ADVICE :
LUD-181206
ASSEMBLY INSTRUCTIONS
2
30
We suggest you spend a short time reading
1.
through this leaflet and then follow the simple
step by step instructions.
If you follow the instructions carefully, the end
2.
result should be worth the effort.
Do not discard any of the packaging until you
3.
have checked that you have all the parts and
the pack of fittings.
Assemble this product on a carpet.
4.
To ensure an easier assembly, we strongly
5.
advise that all fittings are only finger-tightened
during initial assembly phase. Only upon
completion of the assembly should all fixing
points be fully tightened.
We recommend a periodic check on all fixing
6.
points to make sure they remain fully tightened.
Keep any fittings out of children's reach.
7.
ADELE 5FT & 6FT BED
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Dunelm ADELE 5FT
Summary of Contents for Dunelm ADELE 5FT
- Page 1 Page 1 of 6 ADELE 5FT & 6FT BED LUD-181206 ASSEMBLY INSTRUCTIONS Minimum No. Of People Recommended To Assemble This Product : Approximate Assembly Time : MINUTES We suggest you spend a short time reading BEFORE YOU through this leaflet and then follow the simple START, HERE step by step instructions.
-
Page 2: Parts And Hardware Lists
Page 2 of 6 ADELE 5FT & 6FT BED PARTS AND HARDWARE LISTS x2pcs x2pcs x1pc x1pc Siderail Headboard Footboard x4pcs x1pc x28pcs x1pc Wooden Leg Central Rail Sprung Slat Across Bar x1pc x16pcs x2pcs M8x40mm M8x25mm x2pcs x4pcs x2pcs... - Page 3 Page 3 of 6 ADELE 5FT & 6FT BED STEP 1 Fix the Wooden Legs (6) to the bottom of the Headboard (1) and Footboard (2) STEP 2 Attach the Screw (B) and slightly tighten with Allen Key (A). Mount both Siderails (3) to Headboard (1) and Footboard (2) by pushing the Bracket (D) down to fit.
- Page 4 Page 4 of 6 ADELE 5FT & 6FT BED STEP 4 Attach the Central Rail (5) to the Headboard (1) and Footboard (2) with Screw (E) and Bracket (F) STEP 5 Attach Across Bar (8) to the bottom of the Sideral shelf (3) using Screw (I), Washer (J) and Hex Nut (K) with the smaller Allen Key (M).
- Page 5 Page 5 of 6 ADELE 5FT & 6FT BED PROBLEMS? SHOULD YOU ENCOUNTER ANY DIFFICULTY WITH THE ASSEMBLY OF YOUR BED, PLEASE DO NOT TROUBLE YOUR RETAILER BUT CALL, FAX, E-MAIL or WRITE to our CUSTOMER SERVICES DEPARTMENT BETWEEN THE HOURS OF 9.00am to 5.00pm MONDAY to THURSDAY...
- Page 6 Page 6 of 6 ADELE 5FT & 6FT BED CARING FOR YOUR NEW LIMELIGHT PRODUCT PLEASE NOTE: GOODS THAT NEED TO BE RETURNED SHOULD BE SENT BACK IN ITS ORIGINAL PACKAGING. When assembling your bed, please ensure that you have checked the contents for all relevant parts.
