- Page 1 Si011357EA REMOVAL PROCEDURE S E R V I C E M A N U A L 3.5 kW Class 13000/15000 Btu/h Class Outdoor Unit Non-Inverter Pair Type...
- Page 2 Service Manual Removal Procedure Outdoor Unit Cooling Only ARM13MV2S RM13NV2S RM15NV2S RM35JV14 RM35KV1V RN35JV1G...
- Page 3 Si011357EA Table of Contents 1. Outer Panels / Fan Motor................2 2. Electrical Components / Sound Blankets ..........8 3. Capillary Tube ..................10 4. Compressor ASSY ................11 Note: The illustrations may be slightly different depending on the model. Removal Procedure...
-
Page 4: Outer Panels / Fan Motor
Outer Panels / Fan Motor Si011357EA 1. Outer Panels / Fan Motor Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Remove the outer panels. Remove the screw and remove the stop valve cover. - Page 5 Si011357EA Outer Panels / Fan Motor Step Procedure Points Remove the 4 screws and remove the discharge grille. (R16335) The discharge grille has 4 hooks. (R16336) Remove the 8 screws of the front panel. (R16337) Front panel Unfasten the 4 hooks The front panel has 4 hooks.
- Page 6 Outer Panels / Fan Motor Si011357EA Step Procedure Points 2. Remove the fan motor. Nut size: M6 Remove the nut and remove the outdoor fan. 10 mm (0.39 inch) (R18954) Align the mark of the outdoor fan with the D-cut section of the motor shaft when reassembling.
- Page 7 Si011357EA Outer Panels / Fan Motor Step Procedure Points Remove the screw and Put the fan motor lead wire remove the fan motor through the back of the fan fixing frame. motor when reassembling so as not to be entangled with the outdoor fan.
- Page 8 Outer Panels / Fan Motor Si011357EA Step Procedure Points 3. Remove the right side panel. Remove the 7 screws on the terminal board and disconnect the connecting wire and the power supply wire. Remove the screw and remove the wire fixture. Terminal board Wire fixture Connecting...
- Page 9 Si011357EA Outer Panels / Fan Motor Step Procedure Points Remove the 4 screws on the right side. Right side panel (R15238) Remove the screw near the connection port. (R15239) Unfasten the upper When reassembling, make hook. sure to fit the hook. (R15240) Unfasten the hook and When reassembling, make...
-
Page 10: Electrical Components / Sound Blankets
Electrical Components / Sound Blankets Si011357EA 2. Electrical Components / Sound Blankets Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Remove the electrical components. (R20755) Pull out the terminals from the magnetic to X1M (1) - Page 11 Si011357EA Electrical Components / Sound Blankets Step Procedure Points Pull out the terminals Compressor lead wire to compressor (S terminal) from the compressor : yellow R (V) capacitor (C1R). Remove the 2 screws S (W) to compressor to loosen the capacitor (R terminal) fixing band and remove : red...
-
Page 12: Capillary Tube
Capillary Tube Si011357EA 3. Capillary Tube Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Be careful not to get yourself burnt with the pipes and other parts that are heated by the gas brazing machine. -
Page 13: Compressor Assy
Si011357EA Compressor ASSY 4. Compressor ASSY Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Be careful not to get yourself burnt with the pipes and other parts that are heated by the gas brazing machine. - Page 14 Compressor ASSY Si011357EA Step Procedure Points Disconnect the compressor lead wires. Remove the gasket. Gasket S (W) C (U) R (V) (R15393) R ( V ) C ( U ) (R17183) S ( W ) ( R20756 ) S (W): yellow C (U): blue R (V): red Remove the 3 nuts of...
- Page 15 Si011357EA Compressor ASSY Step Procedure Points Heat up the brazed part of the suction side pipe and disconnect it. (R20758) Suction side pipe Lift the compressor ASSY up and remove it. Compressor ASSY (R15471) Removal Procedure...
- Page 16 Revision History Month / Year Version Revised contents 08 / 2013 Si011357E First edition 09 / 2014 Si011357EA Model addition: ARM13MV2S, RM13/15NV2S, RM35JV14, RM35KV1V...
- Page 17 Improper installation can result in water or refrigerant leakage, electrical shock, fire or explosion. Use only those parts and accessories supplied or specified by Daikin. Ask a qualified installer or contractor to install those parts and accessories. Use of unauthorised parts and accessories or improper installation of parts and accessories can result in water or refrigerant leakage, electrical shock, fire or explosion.
