VERSION # 20-09-0 7
1 / 9
MODEL #
CM3212T
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
TOOLS REQUIRED
Allen Wrench
(Included)
Wrench
(Included)
2 - People
Recommended
ASSEMBLY RATING
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM3212T
Summary of Contents for Furniture of America CM3212T
- Page 1 MODEL # CM3212T Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) TOOLS REQUIRED Allen Wrench (Included) Wrench (Included) 2 - People Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X X X 9...
- Page 5 TABLE CM3212T Please keep instructions for future reference. Check the quantity and irregularity of parts and hardware before you start. PARTS #1 1pc #2 2pcs #3 2pcs #4 2pcs #5 6pcs Table Top Bottom Leg Leaf Support Panel Pedestal HARDWARE...
- Page 6 CM3212T is packed in 2 cartons Disignation Part Hardware Carton #A x 14pcs #B x 26pcs Table To p #C x 26pcs #D x 1pc #E x 12pcs #F x 1pc Leaf CM3212T-1 Support Panel Bottom Leg Pedestal CM3212T-2 6 / 9...
- Page 7 ASSEMBLY INSTRUCTIONS Part #4 x2pcs Part #5 x6pcs Hardware #B x12pcs Hardware #C x12pcs Hardware #E x12pcs 1. Place the pedestal (#4) face down. 2. Insert the threaded ends along the bottom legs (#5) into the holes located around the pedestal (#4), then apply a flat washer (#C), lock washer (#B) and a hex nut (#E) in that order onto the ends.
- Page 8 ASSEMBLY INSTRUCTIONS Part #1 x1pc 1. Place the table top (#1) Hardware #A x8pcs face down onto a protected Hardware #B x8pcs surface, then place the pedestals (#4) face down Hardware #C x8pcs onto the table top. 2. Prepare 6 bolt asse- mblies by first insert- ing a lock washer (#B) onto the bolt (#A) then...
- Page 9 ASSEMBLY INSTRUCTIONS Slide the outer ends of the table top (#1) inwards and secure the latches. 9 / 9...
