- Page 1 User Guide ION F10 Power Backup 850VA/490W ION F10 850VA User Guide...
-
Page 3: Table Of Contents
ION F10 850VA User Guide Contents Important Safety Instructions _______________________________ 4 Installing your UPS System __________________________________ 5 Basic Operation ____________________________________________ 8 Technical Specifications ____________________________________ 10 LED Indicator _____________________________________________ 12 Troubleshooting ___________________________________________ 13 Software __________________________________________________ 14 ION F10 User Guide www.ionups.com.au... -
Page 4: Important Safety Instructions
Instruction This manual contains important instructions that should be followed during installation and maintenance of the ION F10 UPS and batteries. Please read and follow all instructions carefully during installation and operation of the unit. Read this manual thoroughly before attempting to unpack, install, or operate. -
Page 5: Installing Your Ups System
The box should contain the following: UPS Unit User Manual OVERVIEW The ION F10 UPS ensures consistent power to your computer system and its included software will automatically save your open files and shutdown your computer system during a utility power loss. - Page 6 The power demands of these devices will overload and possibly damage the unit. 3. Plug the ION F10 UPS in a 2 pole, 3 wire grounded receptacle (wall outlet). Make sure the wall branch outlet is protected by a fuse or circuit breaker and does not service equipment with large electrical demands (e.g.
- Page 7 ION F10 850VA User Guide 5. If an overload is detected, an audible alarm will sound and the unit will emit one long beep. To correct this, turn the UPS off and unplug at least one piece of equipment from the outlets. Wait 10 seconds. Make sure the circuit breaker is depressed and then turn the UPS on.
-
Page 8: Basic Operation
ION F10 850VA ION F10 850VA Basic Operation Description ION F10 850VA Description 1. Power On/Off Switch. Press the power switch to turn the UPS ON or OFF. 2. LED Indicator The LED Indicator shows using AC, using battery, and fault. Refer to “LED Indicator”... - Page 9 ION F10 850VA User Guide 5. Input power cord Connect to utility power. 6. USB Communication Port This port allows connection and communication from the USB port on the computer to the UPS unit. 7. Communication Protection Ports (RJ45&RJ11) Communication protection ports will protect any standard modem, fax, telephone line, or network cable.
-
Page 10: Technical Specifications
ION F10 850VA Technical Specifications MODEL F10-850VA OUTPUT Output Power Capacity 490W/850VA Max Configurable Power 490W/850VA Nominal Voltage (Batt.mode) 220-240Vac Frequency (Batt.mode) 50/60±1% Hz Waveform (Batt.mode) Simulated Sinewave THDv ≤ 3% @ linear load, ≤5%@non-linear load Transfer Time 4ms typical... - Page 11 ION F10 850VA User Guide UPS PHYSICAL Maximum Height 90mm Maximum Width 110mm Maximum Depth 309mm Net Weight COMMUNICATION RJ 11/45 MANAGEMENT Auto Recharge Auto Restart Power Management Software ENVIRONMENT Operation Temperature 0-40°C Operation Humidity 0-90% non-condensing CONFORMANCE Approvals Standard Warranty...
-
Page 12: Led Indicator
ION F10 850VA Indicator ALARM CONDITION Normal Flash Beep 1 time In Utility Failure - The UPS is providing Every 30 Seconds battery power to outlets. Flash Beep 1 time In Utility Failure - The UPS is providing Every 2 Seconds battery power. -
Page 13: Troubleshooting
ION F10 850VA User Guide Troubleshooting PROBLEM POSSIBLE CAUSE SOLUTION The outlets stop Circuit breaker has Turn the UPS off and providing power to tripped due to an unplug at least one piece equipment. Circuit overload. of equipment. Reset breaker button is... -
Page 14: Software
ION F10 850VA Software Download Power Master management software provides a user-friendly interface for your power systems. The graphic user-interface is intuitive and displays essential power information at a glance. Please follow procedure below to install the software. Power Master... - Page 15 ION F10 850VA User Guide...
- Page 16 info@ionups.com.au www.ionups.com.au P: 1300 700 805...
