# = Functional Parts
* = Non-Illustrated Parts
PLEB30T8ACA
UPPER OVEN
POS. NO
PART NO
1
318066402
2
318102101
2A
318071705
6
318025304
6A
5303311206
6B
318025402
9
5303317977
10
5303317976
12
318089910
14 #
5308011085
15 #
3201908
16
3201911
17
5304400195
37 #
316111203
41
5303310526
54
5303310514
58A
318133744
58B
318133769
59
318072506
62 #
5303310518
66 #
5303310513
67 #
5303310512
68
5304403015
70
5303300142
76
318056202
80
318192400
81
5303320846
82
318072301
83
318089609
86
5303310524
88
5303311222
89 #
318095934
89*#
318120710
107
318119600
108#
318073012
109
5303311203
111
5303311205
119#
318004900
125#
5303311202
127
5303310542
128
5303311163
129
5303311164
131
318102301
132
318101700
132A
318101701
177
318053800
185
318014700
222
318080000
263
5303322885
264
318143815
* #
318078507
*
08002868
*
5303211311
*
5303302745
*
5303311528
*
5303323139
DESCRIPTION
Panel,main back
Shield,oven top
Shield,oven top
Rack,oven
Shelf,broiler pan
Shelf,oven
Pan,broiler
Insert,broiler pan
Switch,oven light ,door frame
Receptacle,oven light
Light,oven
Cover,oven light ,glass
Retainer,light cover
Sensor,oven temp probe
Cover,hinge cutout
Housing,oven light
Insulation,oven wrapper
Insulation,oven back
Tube,oven vent
Terminal Block
Element,broil ,2750 W
Element,bake ,3000 W
Support,element hanger
Shield,insulation
Front,oven
Spring,oven
Plate,oven mtg
Shield,oven bottom
Liner,oven
Receptacle,hinge
Rod,latch
Motor,latch assy ,w/brkt & switch
Switch,cooktop shutoff
Cover,fan
Motor,blower
Blade,fan
Nut,fan retainer
Switch,thermal
Motor,convection
Adapter,vent tube ,with converter
Bushing
Spring
Cover,control housing
End,cover ,RH ,control housing
End,cover ,LH ,control housing
Gasket,vent
Spacer,oven shield
Plate,oven temp probe
Spacer,fan blade
Shield,wire
Box & wires assy
Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box
Screw,8 x 0.500
Screw,10-16x1-1/8 ,square drive
Screw,oval hd sq dr ,6-20AB x 0.625 ,black
Screw,10-24 x 0.906
5
Publication No.
5995361036
11/01
