Summary of Contents for DMP Electronics 714-8/16
- Page 1 INSTALLATION GUIDE 714-8/16 and 715-8/16 Zone Expanders...
- Page 2 The enclosure can be surface or flush mounted using the holes provided. Each of the four sides have dual 1/2 in. and 3/4 in. conduit knockouts for running wires out of the enclosure. 714-8/16 and 715-8/16 Installation Guide | Digital Monitoring Products...
- Page 3 100 Ohms 100 Ohms Zone Ground Fault 1500 Ohms or less 1500 Ohms or less 80 Ohms or less Zone Supervision All Zones All Zones All Zones Table 1: Zone Expander Specifications 714-8/16 and 715-8/16 Installation Guide | Digital Monitoring Products...
- Page 4 Mounting Hole Set the Zone Expander Address 714-8/16 and 715-8/16 Point Zone Expanders use two rotary switches (TENS and ONES) to set the zone expander address. For keypad bus addresses, the ONES switch must be set to a starting address that communicates the status of the first four zones (Z1 through Z4) on the expansion module.
- Page 5 683 - 698 783 - 798 883 - 898 983 - 998 584 - 599 684 - 699 784 - 799 884 - 899 984 - 999 Table 3: LX-Bus and Corresponding Zone Numbers 714-8/16 and 715-8/16 Installation Guide | Digital Monitoring Products...
- Page 6 Guide. Otherwise, 714/715 zones can only be used in low risk applications. ULC Residential Fire (XR150/XR550 Series Panels) Refer to the appropriate panel compliance listing guide for the complete list of UL approved smoke detectors. 714-8/16 and 715-8/16 Installation Guide | Digital Monitoring Products...
- Page 7 SPECIFICATIONS Operating Voltage 8.8 to 15.0 VDC Operating Current 714-8/16 Average 20 mA + 1.6 mA per zone Alarm 20 mA + 2 mA per zone 715-8/16 Average 20 mA + 4 mA per zone + 0.1 per 2-wire smoke Alarm 20 mA + 58 mA per shorted zone + 0.1 per 2-wire smoke...
