Summary of Contents for Crosley Sedona CO600142-BK
- Page 2 PARTS LIST Stretcher 4 PCS 1 PC 1 PC HARDWARE LIST Cylinder Bolt (M8) (M8) (M8) (M8) (M8*25) 4 PCS Bolt Wrench Flat washer Bolt cap (M6*30) (M6) (M6) (M6) 8 PCS 1 PC 8 PCS 8 PCS...
- Page 3 Bolt (M8*25) Spring Washer (M8) Flat Washer (M8) Step 1: Place Top (A) Nut (M8) upside down on a soft cloth. Nut Cap (M8) Bolt (M6*30) Insert all Cylinder Bolts (Part #1) into Flast Washer (M6) the pre-drilled holes o op (A). Bolt Cap (M6) Step 2: Attach two adjacent Legs (B) to Top (A) by inserting the Cylinder...
