INSTRUCTION MANUAL

ONTAGUE

Heavy Duty Ranges

M12, M18, M24 & M36 Series

These instructions should be read thoroughly before attempting installation.

Set up and installation should be performed by qualified installation personnel.

Keep area around appliances free and clear from combustibles.

Gas Fired

MODELS:

12, 18, 24 & 36 Series

124 & 136 Series

PLEASE RETAIN THIS MANUAL

FOR FUTURE REFERENCE.

ONTAGUE

1830 STEARMAN AVENUE, P.O. BOX 4954

HAYWARD, CA 94540-4954

TEL: 510/785-8822 FAX: 510/785-3342

OMPANY

Need help?

Do you have a question about the Legend 12 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for MONTAGUE Legend 12 Series

Page 1 INSTRUCTION MANUAL ONTAGUE Gas Fired Heavy Duty Ranges MODELS: 12, 18, 24 & 36 Series M12, M18, M24 & M36 Series 124 & 136 Series These instructions should be read thoroughly before attempting installation. Set up and installation should be performed by qualified installation personnel. Keep area around appliances free and clear from combustibles.
Page 2 CONTENTS INSTALLATION ... . . 1 MAINTENANCE ....16 OPERATION ....8 SERVICE .
Page 3 INSTALLATION The Montague gas ranges are manufactured for use with the type of gas indicated on the nameplate. The Montague heavy duty gas ranges are produced with the best possible material and workmanship. PROPER INSTALLATION IS ESSENTIAL FOR SAFE AND EFFICIENT TROUBLE-FREE OPERATION.
Page 4 INSTALLATION VENTILATING HOOD The range(s) must be installed under a properly designed ventilating hood. The hood should extend at least 6" beyond all sides of the unit. the hood should be connected to an adequate mechanical exhaust system. Information on the construction and installation of ventilating hoods may be obtained from the "Standard for the Installation of Equipment for the Removal of Smoke and Grease Laden Vapors from Commercial Cooking Equipment", NFPA No.
Page 5 INSTALLATION ASSEMBLY Uncrate range as near to final location as possible. Remove all shipping wire from burners and all packing material and accessories from oven interior. Then assemble as follows: Screw the adjustable feet of the legs in all the way. Then tightly screw the complete leg assembly into the mounting holes at each corner of the range.
Page 6 SERVICE MODULAR RANGES: Assemble modular base and set in place. Adjust feet as explained above. Connect ranges as shown for battery arrangement. FRY TOP RANGES: Fry Top Plate Adjustment: Leveling bolts are at the rear of the range under the fry top plate. Adjust leveling bolts so that the plate is pitched to the front to provide for grease runoff.
Page 7 SERVICE The gas pressure regulator furnished by the installer must comply with the following: 1. The pressure regulator(s) must have a maximum regulation capacity for the total connected load. 2. The pressure regulator(s) installed must be listed by a nationally recognized testing agency. 3.
Page 8 SERVICE TEST ALL PIPE JOINTS FOR LEAKS BEFORE OPERATING RANGE(S). THIS INCLUDES ALL GAS CONNECTIONS THAT MAY HAVE LOOSENED DURING SHIPMENT. USE A RICH SOAP SOLUTION (OR OTHER ACCEPTED LEAK TESTER) AROUND ALL PIPE CONNECTIONS AND ALL OTHER JOINTS. DO NOT USE AN OPEN FLAME. ABSOLUTELY NO LEAKAGE SHOULD OCCUR, OTHERWISE THERE IS A DANGER OF FIRE OR EXPLOSION DEPENDING UPON CONDITIONS.
Page 9 SERVICE FRY TOP AND OVEN THERMOSTATS The bypass (minimum burner flame) has been adjusted at factory and should require no further adjustment if the gas manifold pressure is correct. THE BYPASS FLAME MUST BE RECHECKED WHEN PERFORMING CHECKOUT OF RANGE PRIOR TO PLACING EQUIPMENT IN SERVICE. THE BYPASS MUST BE SET CAREFULLY AND ACCURATELY.
Page 10 SERVICE OPERATING INFORMATION FOR THE RANGE HAS BEEN PREPARED FOR USE BY QUALIFIED AND/OR PROFESSIONAL OPERATING PERSONNEL. CAUTION DO NOT OBSTRUCT THE FLOW OF COMBUSTION AND VENTILATION AIR TO THE RANGE. KEEP THE APPLIANCE AREA FREE AND CLEAR FROM COMBUSTIBLES. GAS CONTROLS IN THE EVENT A GAS ODOR IS DETECTED, SHUT DOWN UNITS AT MAIN SHUT OFF VALVE AND CONTACT THE LOCAL GAS COMPANY OR GAS...
Page 11 SERVICE OVEN OPERATION - 136 SERIES 1. Turn burner valve "ON" and turn thermostat dial to desired temperature. 2. Limit preheat time to 20 to 30 minutes. 3. Place food in oven. Make sure pans do not touch each other, or the oven walls. 4.
Page 12 SERVICE SUGGESTIONS Break the habit of turning on all your equipment first thing every morning. Unless you plan to use a piece of equipment, leave it off until it's needed. There is no need to preheat an open top burner. Use full flame to start foods cooking quickly;...
Page 13 SERVICE OVEN INTERIOR STANDARD FINISH (Porcelain Enamel): Frequent cleaning is required. Spillovers should be cleaned as soon as possible to prevent carbonizing and a burnt-on condition. Wait until oven is cool for complete cleaning. Usually a soap or detergent solution is strong enough to remove any grease residue.
Page 14 SERVICE WHEN SERVICE IS NEEDED, CONTACT A LOCAL SERVICE COMPANY, DEALER, OR FACTORY TO PERFORM MECHANICAL MAINTENANCE AND REPAIRS. THESE INSTRUCTIONS ARE INTENDED FOR USE BY COMPETENT SERVICE PERSONNEL. CAUTION: TURN OFF GAS SUPPLY WHEN SERVICING GAS CONTROL SYSTEM. SAFETY PILOT VALVE Model H15HR is an automatic 100% safety pilot which provides complete gas shut off in event of pilot...
Page 15 SERVICE If the closed circuit check shows thermocouple output is greater than 8 millivolts and pilot will not remain lit when reset button is released, replace safety pilot valve. 3. Thermocouple lead connections must be tight, clean, and free of grease. The thermocouple nut should be started and turned all the way by hand.
Page 16 SERVICE 1. Fry Top plate 2. Shield 3. Screw, holding 4. Bracket,support 5. Insulated block 6. Backing plate 7. Sleeving Thermostat Sensing Bulb Holder Assembly ADJUSTMENT OF BYPASS (MINIMUM BURNER) FLAME This is the flame which must be maintained on the burners when the fry top has reached the temperature set on the dial.
Page 17 SERVICE THE BYPASS MUST BE SET CAREFULLY AND ACCURATELY AS FOLLOWS: 1. Light burners and turn Dial (A) counterclockwise and to a point midway between the “Gas On” mark and the next graduation to the right of it (shown by “V). If the burner goes out entirely, the bypass is closed.
Page 18 SERVICE Field recalibration is seldom necessary, and should not be resorted to unless experience with cooking results definitely proves that the control is not maintaining the temperature to which the dial is set. To check oven temperatures when recalibrating use a Robertshaw Test Instrument or a reliable mercury oven thermometer.
Page 19 SERVICE THERMOSTAT CALIBRATION CHECK: - 136 SERIES 1. Place the thermocouple of test instrument or thermometer in the middle of the oven. 2. Light the main burner. 3. Turn dial so 400 lines up with the indicator mark on dial stop. 4.
Page 20 SERVICE ADJUSTMENT OF BYPASS (MINIMUM BURNER) - 124 SERIES This is the flame that must be maintained on the burners when the oven has come up to the temperature set on the dial. Enough gas must be bypassed by the control to keep the entire burner lit.
Page 21 SERVICE OVEN THERMOSTAT CALIBRATION CHECK: - 124 SERIES The oven temperature should be checked or recalibrated with oven hot. NOTE: see "Adjustment of Bypass (Minimum Burner) Flame" above before recalibrating this thermostat. HOT CHECK METHOD - 136 SERIES 1. Place the reliable thermometer in center of oven. º...
Page 22 SERVICE OVEN TEMPERATURE HIGHER THAN DIAL SETTING: 1. Oven thermostat out of calibration. 2. Minimum flame too high. (Do not lower under 1/8"). 3. Broken capillary tube on thermostat. 4. Dirt under thermostat valve seat. Orifice Size Chart Drill Size (FRONT) (REAR) A.
Page 24 124 & 136XLB Series Only Item .. Part # ..Description Item ... Part # ..... Description 1 ..8955-9 ....Door Panel , Ext . - ptd (with nameplate) 1 ..7644-9 ....Door Panel, Ext. - S/S (with nameplate) 1 ..
Page 28 In order to establish full compliance with Proposition 65, we attached a yellow warning label to each gas fired unit manufactured by the Montague Company. Carbon monoxide would not be present in concentrations that would pose a "significant risk" to the consumer when the...
Page 29 Serial No. _________________________________________ Model No._________________________________________ Change No.________________________________________ Name & No. of Part Model No. Change No. Serial No. The Montague Company 1830 Stearman Avenue P.O. Box 4954 Hayward, CA 94540-4954 (REV. C) P/N 4527-6 11/05...
