Spinner A77136C0001 Installation Manual

Installation guide for
In-Building panel antennas

1 Introduction and safety advice

This instruction shall provide information how to install the antenna with mounting kits.
All shown tasks are intended to be carried out by qualified personnel only. Safety rules apply
(e.g. for working with heavy loads, radio frequency power signals or tools). In order to prevent
damage to equipment and humans, make sure that no RF power is present at the combiner
during installation.
Please note that satisfactory performance of the system (especially in terms of inter-
modulation) can only be achieved if all jumper cables and connectors are handled properly.
Please make sure that all connectors are clean and free from metal, dust or dirt. Avoid sharp
bending of the connecting jumper cables.
After carrying out all described steps, the antenna is ready for use. Make sure that the specified
environmental conditions for operation are not exceeded.
SPINNER does not guarantee for any faults or damage resulting from improper installation.
