Spinner A77137 Quick Start Manual

Advertisement

Installation guide for
In-Building omni antennas

1 Introduction and safety advice

This instruction shall provide information how to install the antenna with mounting kits.
The installation of Thin Omni Chip antennas is not recommended for metal ceilings or nearby any
metallic materials. Additional Isolation/Absorbing accessories can be applied for improving the
Antenna VSWR value.
Omni antennas must not be rotated after connecting the feeder cables.
All shown tasks are intended to be carried out by qualified personnel only. Safety rules apply (e.g.
for working with heavy loads, radio frequency power signals or tools). In order to prevent damage
to equipment and humans, make sure that no RF power is present at the combiner during
installation.
Please note that satisfactory performance of the system (especially in terms of intermodulation)
can only be achieved if all jumper cables and connectors are handled properly. Please make sure
that all connectors are clean and free from metal dust or dirt. Avoid sharp bending of the
connecting jumper cables.
After carrying out all described steps, the antenna is ready for use. Make sure that the specified
environmental conditions for operation are not exceeded.
SPINNER does not guarantee for any faults or damage resulting from improper installation.
Data subject to change without notice – June.09.2021 (F)
