Officeworks FD05 Assembly Instructions Manual

Regency desk

Download this manual

Important:

Lay out all of the parts on a non-abrasive surface in order to avoid scratching, then identify and

count prior to assembly.

If you are missing any hardware components from the Hardware List or need assembly assistance, please

contact UBIZ Furniture on

Tel: (03) 9357 5800 Fax: (03) 9357 5811 / Email: smallparts@ubizfurniture.com

If you are missing any parts from the Parts List please contact your store of purchase.

Need help?

Do you have a question about the FD05 and is the answer not in the manual?

Page 1 Important: Lay out all of the parts on a non-abrasive surface in order to avoid scratching, then identify and count prior to assembly. If you are missing any hardware components from the Hardware List or need assembly assistance, please contact UBIZ Furniture on Tel: (03) 9357 5800 Fax: (03) 9357 5811 / Email: smallparts@ubizfurniture.com If you are missing any parts from the Parts List please contact your store of purchase.
Page 2: Parts Identification
PARTS IDENTIFICATION Front left / Back right leg 2 PCS Front right / Back left leg 2 PCS Left side lower crossbar 1 PC FRONT 1 PC Right side lower crossbar FRONT Back Lower crossbar 1 PC Upper metal frame 1 PC Top panel 1 PC...
Page 3: Hardware Identification
HARDWARE IDENTIFICATION Allen bolt ( 6 x 12mmL ) 18 PCS Allen bolt ( 6 x 51mmL ) 4 PCS Allen key 1 PC Front Locking caster 2 PCS Back Non - Locking caster 2 PCS 1 PC Spanner Page 3 of 6...
Page 4 STEP 1 STEP 2 Page 4 of 6...
Page 5 STEP 3 STEP 4 Page 5 of 6...
Page 6 Reminder : Dont press the button of lock with hand for it may hurt your hand. Maximum Load Capacity Product overall size : 1200W x 600D x 760mmH Page 6 of 6...
