ASSEMBLY INSTRUCTIONS
BAKU MEDIUM BACK CHAIR
JBBAKUMBBK/JBBAKUMBWH
Weight capacity: 120kgs
This design and instruction booklet is subject to copyright.
www.officeworks.com.au
1CTN
For spare parts or hardware call (03) 9310 3011 or email hardware@kyvas.com.au
1/9
Advertisement
Related Manuals for Officeworks OTTO JBBAKUMBBK
Summary of Contents for Officeworks OTTO JBBAKUMBBK
- Page 1 ASSEMBLY INSTRUCTIONS BAKU MEDIUM BACK CHAIR JBBAKUMBBK/JBBAKUMBWH Weight capacity: 120kgs This design and instruction booklet is subject to copyright. www.officeworks.com.au 1CTN For spare parts or hardware call (03) 9310 3011 or email hardware@kyvas.com.au...
- Page 2 Assembly Video • To view an assembly video, go to https://www.officeworks.com.au/ • Search the product by item code or name: Officeworks Search for a product make bigger things happen • Click on the icon to watch the video. Video (03) 9310 3011...
-
Page 3: Part List
PART LIST HARDWARE LIST M6*25mm M6*20mm M6*40mm... - Page 4 Step 1 Note: Turn the Star Base ( F ) upside down. PUSH the Castors ( G ) firmly in the hole at the end of each leg. Turn the Star Base ( F ) upright and insert Gas Lift ( E ) into the center hole of Star Base ( F ).
- Page 5 Step 3 Note: Attach the armrests to the seat using 4 x Screws ( J ) and 4 x washers( K ) with Allen Key ( N ). Step 4 Note: Align the Seat Plate ( D ) so the FRONT of the Seat plate ( D ) faces the FRONT...
- Page 6 Step 5 Note: Place assembled seat on the Gas Lift ( E ). Push down firmly until connection is secure. Fully tighten all screws. Step 6...
- Page 7 • Avoid contact with skin, in particular during high temperatures and humidity. • Clean, check and tighten all parts regularly. • Vacuum regularly. Thank you for your purchase. Please retain your receipt to validate warranty. If you would like to know more about our furniture products, please visit www.officeworks.com.au...
- Page 8 Baku Medium Back Chair Functionality Flip Back Armrest FLIP BACK ARMREST Chair Tilt - Sitting in the chair pull lever up. Move your upper body fore and aft to a comfortable position. When comfortable lock the position by pushing the lever down. Chair Height Adjustment - To increase chair height pull lever upward while lifting body weight...
- Page 9 Warranty 3 years Product Warranty – valid for Australian customers only Officeworks Ltd warrants that this product will be free from defects and work as intended for 3 years from the date of purchase by the original customer. If the product has any defects or does not work as intended during the Warranty Period, Officeworks will, at its election and at its expense, repair or replace the product.
