rock space RSD0607 Quick Installation Manual

Quick Installation Guide
AC750/AC1200 Dual Band Wi-Fi Extender
Model No. RSD0607/ Model No. RSD0608
1

Power On

Plug the extender into a power outlet next to your router.
Wait until its Power LED turns blue.
2

Set Up

Method 1: Via a Web Browser

Method 1:Via a Web Browser
1
1 . Connect your computer or smartphone to the extender's
. Connect your computer or smart phone to the extender's
network "rockspace_EXT " .When you are using a computer,
network "rockspace_EXT " . When you are using a computer,
unplug the Ethernet cable if any. When you are using a
unplug the ethernet cable if any. When you are using a
mobile phone, ensure the mobile data is disabled.
smart phone, ensure the mobile data is disabled.
WLAN
rockspace_EXT
2
.Launch a web browser and enter http://192.168.0.254 or
http://re.rockspace.local in the address bar. Create a login
password and record it down for later use.
*Note: If the login window does not appear, refer to FAQ > Q1.
192.168.0.254
Password (5-32 characters)
PWR
3
. Select the Wi-Fi network (SSID) you want to extend.
Select a Wi-Fi network you want
to extend...
Rescan
4
. Enter the password of the Wi-Fi network you want to extend.
Your existing Wi-Fi network
The extended WiFi network
SSID
By default, the password of the
extended network is same as your
existing Wi-Fi network.
Back
Wait until the page shows you "Extended successfully"!
Reset Pinhole Ethernet Port
Next Not Now
Switch Mode
"
_5GEXT
Extend

Meet Your Extender

This LED indicates the connection
Signal LED
between the extender and the router.
Blue
Best connection
Red
Poor connection
No connection
WPS LED
Signal LED
On
WiFi security is enabled (WPA or WPA2).
WPS LED
Power LED Blinking
WPS connection is in progress.
WPS Button
Power LED
Solid on
The extender is powered on.
Blinking
The extender is booting.
The extender is powered o .

Method 2: Via the WPS Button

1
. Press the WPS button on the router.
2. Within 2 minutes, press the WPS button on the extender.
Press
3
. Wait until the Signal LED on the extender turns blue ,
indicating successful connection. If the Signal LED does not
turn blue, try Method 1.
Relocate the
3
Wi-Fi Range Extender
1.
Plug in the extender about halfway between your router
and the Wi-Fi dead zone. The location you choose must be
within the range of your router.
2.
Wait for about 2 minutes until the Signal LED turns blue.
If it doesn't, relocate the extender closer to the router to
achieve better signal quality.
Antennas upward and vertical to the ground
WiFi router
Signal
Blue: suitable location
Red: too far from the router
