rock space RSD0607 Quick Start Manual

Quick Start Guide
AC750/AC1200 Dual Band WiFi Repeater
Model: RSD0607/RSD0608
Technical Phone Support: +1(833)816-6558
Service Time: EST: 9:00-17:00 / PDT: 06:00-14:00,from Monday to Friday
24hour Online After-sales Service: https: //rockspace. afterservice. vip
The website list above is the ONLY official after sales service website
that's been authorized.
Please DO NOT trust the other websites for technical support.
Connect to an Existing WiFi Network with Web Browser Setup
Method 1:
1
Place the Extender and
Apply Power
Place your extender in the same room as your
WiFi router. Plug the extender into an electrical
outlet.
Wait for the Power LED to light blue.
3
Relocate the WiFi Range Extender
1.
Unplug the extender and move it to a new location about halfway
between your router and the area with a poor WiFi signal.
The location that you choose must be within the range of your existing
WiFi router network.
2.
Plug the extender into an electrical outlet and wait for the Signal
LED to light blue. If not, plug the extender into an outlet closer to the
router and try again.
3.
Use a WiFi network manager on your client device, such as a computer
or WiFi device, to nd and connect to the extended WiFi network you've
set up in the previous step.
Note: The password for the extended network is the same as the password
for your existing WiFi network.
4.
After connecting to the repeater wireless signal,enter domain name:re.rockspace.local in the address bar to login.
2
Extend Your WiFi Network
1
. Use a WiFi network manager on your client device,
such as a computer or WiFi device, to nd and connect
to the "rockspace_EXT " (SSID) WiFi network.
Ensure that the Mobile Data is disabled.
2
. After the connection with your client device is
established, the setup page will automatically pop up. If
the setup page doesn't pop up automatically, you will
need to launch web browser and enter 192.168.0.254 to
get started. In the Password eld, type the password
that you wish to use to log into the management
interface.
Note: The password you entered in this step is NOT the
password for your extended network, it is the password
PWR
for the extender's management interface.

LED Descriptions

Solid on
Blinking
Power LED
O
On
Blinking
WPS LED
O
Solid blue
Signal LED
This LED indicates
Solid red
the connection
between the
extender and the
O
router.
WLAN
rockspace_EXT
192.168.0.254
Password (5-32 characters)
Con rm
Next Not Now
WiFi router
The extender is powered on.
The extender is booting.
The extender is powered o .
WiFi security is enabled (WPA or WPA2).
A WPS connection is in progress.
WiFi security is not enabled.
Best connection
Poor connection.
No connection.
3
. Select a WiFi network to extend.
Select a WiFi network you want to
extend...
My_home_wi
Rescan Switch Mode
4
. In the password eld, type the password for
the existing WiFi network you previously selected.
Your existing WiFi network
Enter the password of "My_home_wi "
The extended WiFi network
SSID
My_home_wi
Password of the extended network is
same as your existing WiFi network.
Back Extend
The SSID of the extended network can be modi ed,
otherwise it will remain the same as that of the
existing network you chose to extend. Wait for the
page to display a list of WiFi networks, connect your
client device to the new extender WiFi network.
Note: The password for the extended network you
entered in step 4 should be the same as the
password for your existing WiFi network.
Antennas upward and vertical to the ground
Signal
Blue: successfully connected
Red: connection failed
