Philips Home Power SPC1241AT/27 Quick Start Manual

Home power
SPC1241AT/27
Enclosed
A B
A. Plug-in receiver
B. Remote transmitter
C. CR2032 battery
Battery Installation
1. Remove the Phillips-head screw from the back of the remote.
2. Press the tab to release the battery cover and lift the cover from
the remote.
3. Remove the white battery tab to activate the remote.
4. If installing a new battery, place it in the battery compartment
with the (+) side facing up.
5. Replace the battery cover and install the screw.
Receiver Installation
1. Plug lamp or device controlled into the outlet on the side of
the receiver – device's switch must be in the ON position.
2. Plug the receiver into a standard indoor outlet.
Troubleshooting
Problem
Indicator light on remote
does not illuminate when
button is pushed
Indicator on remote
illuminates but light does
not turn on
PLUG-IN RECEIVER
Functional range .....................................................................up to 100ft.
Maximum resistive load ................................................................ 1800W
Rating ....................................................................................120VAC/60Hz
REMOTE TRANSMITTER
Functional range .....................................................................up to 100ft.
Battery type ....................................................................................CR2032
C * Functional range may be adversely affected by one or more of the following
factors: weather, radio frequency interference, low transmitter battery and
obstructions between the transmitter and receiver.
CAUTION: TO REDUCE THE RISK OF OVERHEATING AND POSSIBLE DAMAGE TO OTHER
EQUIPMENT, DO NOT INSTALL TO CONTROL A MOTOR-OPERATED APPLIANCE, A
FLUORESCENT LIGHTING FIXTURE OR A TRANSFORMER-SUPPLIED APPLIANCE.
BATTERY MAY LEAK HARMFUL LIQUIDS OR IGNITABLE MATERIALS OR EXPLODE
CAUSING INJURY OR PRODUCT DAMAGE.
• REPLACE FULLY DISCHARGED BATTERY IMMEDIATELY
• REMOVE BATTERY IF PRODUCT IS TO BE UNUSED FOR EXTENDED PERIOD
RISK OF FIRE
• DO NOT EXCEED ELECTRICAL RATINGS
• DO NOT USE TO CONTROL
MOTOR-OPERATED APPLIANCES,
TRANSFORMER-SUPPLIED APPLIANCES
OR APPLIANCES THAT CONTAIN
HEATING ELEMENTS (COOKERS, IRONS,
HEATERS, ETC.)
Suppliers Declaration of Conformity | Model #: SPC1241AT/27 | Jasco
Products Co., 10 E. Memorial Rd, Oklahoma City, OK 73114,
www.byjasco.com
This device complies with Part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC NOTE: The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this equipment.
Such modifications could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy, and if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different to which
the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Corrective Action
• Battery may be installed incorrectly.
Reinstall battery.
• Battery may need to be replaced. Install
new CR2032 battery.
• Make sure light is turned on and
bulb is working
WARNING
RISK OF ELECTRIC SHOCK
• FULLY INSERT PLUG
• KEEP CHILDREN AWAY
• USE INDOORS ONLY
• DO NOT USE IN WET LOCATIONS
• UNPLUG BEFORE CLEANING
THANK YOU FOR YOUR PURCHASE!
Product
instructions
made easy
Scan to watch a step-by-step Get exclusive, web-only deals and
instructional video, or visit more! Scan here, or visit
https://byjasco.com/50866i byjasco.com/deals
Need more
accessories?
For additional lighting controls and
more, visit our website!
byjasco.com/lightingcontrols
MADE IN CHINA
Philips and the Philips Shield Emblem are registered trademarks
of Koninklijke Philips N.V. and are used under license. This product
has been manufactured by and is sold under the
responsibility of Jasco Products Company, and Jasco
Products Company LLC, 10 E. Memorial Rd., Oklahoma
City, OK 73114 is the warrantor in relation to this product.
This product comes with a 1-year limited warranty.
Visit www.philips.com/support for warranty details.
Questions? Contact our U.S.-based Consumer Care
at 1-844-816-0320 between 7AM–8PM, M–F,
Central Time.
Register
your Philips
product
Like our product?
Leave us a review on
Amazon.com or your favorite
retailer website!
Having issues and need
support?
Call our U.S.-based
experts Monday–Friday, from
7AM–8PM (Central)
1-844-816-0320
SPC1241AT/27
v1 06/2020
