4. CONTROL
MENU - USER LOCK
Use this menu to set the limits to control the regulator with a
multi-level panel
Options:
None – Limit inactive
On/Off – Only On/Off and access to the information menu are
enabled in the main screen
On/Off, Temp, Flow – On/Off, the information menu,
and temperature and air flow settings can be accessed without
password.
Full – Only the information menu can be accessed without password
User mode – Special user mode, see image below
MENU - SUMMER HEATING
Use this menu to set heating limits in summer months
Winter mode set by default. Enabling the function allows heating also
in summer
Enable/disable
function
Start of winter
period (month number)
MENU - DOOR CONTACT
Use this menu to set the behaviour of the regulator according to the
door contact
Enable/disable
function
All manuals and user guides at all-guides.com
Limit level – see Ad1)
Enter PIN 0000~9999
(numeric values only)
End of winter period
(month number)
Mode:
Fixed
Fixed mode settings
Ventilation rate with
open doors
(33%-100%)
Heating settings with
Heat open door 0%
open doors
Manual = 0%, 50%, 100%
Rundown function:
Disable
Time interval
Temperature (when
reaching a temperature on
the thermostat)
Timed rundown
MENU - SUBUNITS
Use this menu to set the behaviour of the IC-S regulators
connected as SLAVE
Slave address parameter:
ADDRESS SLAVE UNIT
1 1
2 2
3 3
4 4
5 5
Detailed settings
of the rundown
function
ADDRESS SLAVE UNIT
6 6
7 7
8 8
9 9
A 10
11
