USER MANUAL – – A62208 (2GN) : 930 x 820 x 900 (+430) mm A62213 (3GN) : 1380 x 820 x 900 (+430) mm A62215 (4GN) : 1580 x 820 x 900 (+430) mm A62219 (5GN) : 1930 x 820 x 900 (+430) mm...
These units comply with applicable EC norms and should be installed and used following the instructions in this manual to ensure good performance and to be covered by the warranty. Vauconsant SA, all rights reserved A622xx & E633xx -rev0-ENG, 2/12/2010 - 3 -...
Normal pressure of use: 4 bars. For higher pressure, use a pressure switch to avoid the dysfunction or deterioration of the solenoid valve. Connect the drainage hose to the floor. Vauconsant SA, all rights reserved A622xx & E633xx -rev0-ENG, 2/12/2010 - 4 -...
Page 5
The unit’s overhangs should be positioned as shown below. The unit should be level. Assembly / dismantling of facing • Step 1 Mounting with spanner (rack supply Step 2 Vauconsant SA, all rights reserved A622xx & E633xx -rev0-ENG, 2/12/2010 - 5 -...
Page 6
The controls are placed on a removable panel to the right of the unit. A mechanical thermostat with orange on-off light for the bain-marie well. A switch with orange light for the heating display option. Vauconsant SA, all rights reserved A622xx & E633xx -rev0-ENG, 2/12/2010 - 6 -...
The temperature of the well may be set from 30°C to 110 °C. Heating display (option) Press the switch: position 0 = Off position 1 = On. Vauconsant SA, all rights reserved A622xx & E633xx -rev0-ENG, 2/12/2010 - 7 -...
• Bulbs should be replaced with bulbs of equivalent power. (see the Spare Parts section) • Fuses should be replaced by gG fuses of the same caliber. Vauconsant SA, all rights reserved A622xx & E633xx -rev0-ENG, 2/12/2010 - 8 -...
Electric cabling is fixed behind the built-in control panel. To access this, remove the 4 screws holding the panel. The installer should check electric connections when commissioning the unit then once a year. Any maintenance operation should be done by an electrician. Vauconsant SA, all rights reserved A622xx & E633xx -rev0-ENG, 2/12/2010 - 9 -...
USER MANUAL Electric diagrams Heating element coupling diagram SINGLE-PHASE THREE-PHASE Vauconsant SA, all rights reserved A622xx & E633xx -rev0-ENG, 2/12/2010 - 10 -...
Page 11
Power of the bain-marie well (W) 1 500 2 250 3 000 Unit's total power (W) 1 500 2 250 3 000 gG (A) fuse caliber Vauconsant SA, all rights reserved A622xx & E633xx -rev0-ENG, 2/12/2010 - 11 -...
Page 12
Number of heating elements: 415 mm, 750 W well Power of the bain-marie well (W) 3 750 4 500 Unit's total power (W) 3 750 4 500 gG (A) fuse caliber Vauconsant SA, all rights reserved A622xx & E633xx -rev0-ENG, 2/12/2010 - 12 -...
Page 13
2 250 Heating Number of halogen lamps, 200W display Power of the heating display (W) Unit's total power (W) 1 900 2 850 gG (A) fuse caliber Vauconsant SA, all rights reserved A622xx & E633xx -rev0-ENG, 2/12/2010 - 13 -...
Page 14
Number of halogen lamps, 200W display Power of the heating display (W) 1 000 1 200 Unit's total power (W) 3 800 4 750 5 700 gG (A) fuse caliber Vauconsant SA, all rights reserved A622xx & E633xx -rev0-ENG, 2/12/2010 - 14 -...
In any case, Vauconsant's civil liability, for all causes, with the exception of corporal damage and fraud or serious misdemeanour, may not exceed the sum of the contract.
