- Page 2 Do not use the vehicle in an unsafe manner. Unsafe manner include but are not limited to...
- Page 3 Pay attention while driving the vehicle, avoid falls or collisions causing injury to the user or third parties. Please check the component parts before using, and make regularly examine the transformers or battery chargers for in the event of any Do not mix old and new batteries.
-
Page 4: Specification
Specification Name specification Battery: 12V 4.5AH( 6-FM-4.5（AH）) *1/ Battery 12V 7AH(6-FM-7（AH）)*1 Motor: Motor Steering motor:12V Suitable age 37-96 months Max weight 28KG Body size 992*666*666MM Speed 2-4KM/h Hours of use charging 8-12 hours，using 1 to 2 hours Input：110V~240V Output: DC 12V500MA/ Charger DC 12V1000MA G( spring) - Page 5 Preparation work: Put the car upside down on a soft cloth or smooth plane firstly (Can't be directly placed on the surface of the cement, etc., which will scratch the surface of the plastic), then take off the cardboard, foam, nylon cable ties.
- Page 6 Step 3: Install rear wheels Install I (rear wheel) and screw onto the D(rear axle), then install H (wheel cover) onto the I(rear wheel) finally. Step 5: Install front wheels 1.Loosen the screw and gasket from the C(front axle). 2.Install I (front wheel) , gasket and screw onto the C(front axle), then install H (wheel cover) onto the I(front wheel) finally.
- Page 7 Step 10: Install the backrest 1.Insert the backside of the backrest to the right place [1] (groove at car body), in the meantime, insert the both side of backrest onto right place [2], as shown in figure. 2.Fix the O (backrest) with 2pcs X ( self-tapping screw) at right place as shown in figure.
- Page 8 Press ▼ reverse button, the car goes reverse. Press the P button to brake the car urgently. Press P button again to release the brake system. Press the turn left button, car turn left, Press the turn right button, car turn right, The S button is speed button, one light on is low speed, two lights on for intermediate speed, three lights on for high speed.
- Page 9 5. Operation guide for Manual control (forward, 4-1. Instruction for MP3 multifunction player reverse ): (Configuration A) After the driver is seated, press the power switch, the car will send out a starting sound (2-5seconds). Put the Forward/Backward switch into the position of “forward”...
- Page 10 Resettable fuse: when the current exceeds a certain rating, Trouble elimination methods the recoverable fuse will automatically 1.Yes, the fuse cuts off the power 1. Is the fuse overloaded? cut off the power supply for 5- automatically by 5-20 seconds, then 2.
