Assembly Instructions
CONTACT US FIRST
parts@prepacmfg.com
1-877-PREPAC1
1-877-773-7221
Mon - Fri
7am - 4pm PST
10am - 7pm EST
•
For help with assembly
•
If you have received a damaged or defective
part or are missing hardware.
We will process replacement parts in 2 business
days or less.Parts are shipped via UPS Ground or
mail.
Before you call please:
1)
Record the following information from the
shipping label on the outside of the box.
You will need it for warranty purposes:
Ship To Name
Sales Order Number
2)
Note the product model number.
3)
Review the contents of your shipment to
determine what you are missing.
Online Option
Fill out the Replacement Parts Order form in the Product
Support section of our website: www.prepacmfg.com
Required Tools
Optional Tools
Using a power screwdriver will
speed up assembly.
Caution
Do not over tighten any screw.
The last few turns of each screw
should be done very slowly or by
hand.
3-drawer Nightstand
Model # DNH-0339-1
This product is shipped in
1 carton
Prepac Manufacturing Ltd.
6705 Dennett Place
Delta, BC V4G 1N4
LB-0703
2012-06-18
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Prepac DNH-0339-1
Summary of Contents for Prepac DNH-0339-1
- Page 1 3-drawer Nightstand Assembly Instructions Model # DNH-0339-1 This product is shipped in 1 carton CONTACT US FIRST parts@prepacmfg.com 1-877-PREPAC1 1-877-773-7221 Mon - Fri 7am - 4pm PST 10am - 7pm EST • For help with assembly • If you have received a damaged or defective part or are missing hardware.
-
Page 2: Hardware Identification
Hardware Identification Identification de quincaillerie 24mm Green 15mm Zinc Cam (large) #8 - 1½” Screws (12) Euro Screw (48) ¾” Nail (24) Twister Dowel (12) (12) Vis no.8 - 1½ po. Vis “Euro” Clou ¾” Goujon de torsion vert Ferrure en zinc grand RM-0504 RM-0074 RM-0022... - Page 3 Nightstand Parts Pièces de la table de nuit Top (1) Top Moulding (1) Left Side (1) Right Side (1) Dessus Moulure supérieure Côté gauche Côté droit TP-10011-B black / noir TR-10008-B black / noir SL-10035-B black / noir SR-10035-B black / noir Side Moulding (2) Rear Stabilizer (1) Front Stabilizer (1)
- Page 4 Step 1 Estimated Time: 5 Minutes Attach black spacers to left (C3) and right (C4) sides with Euro screws Attachez les entretoises noires aux côtés gauche (C3) et droit (C4) avec vis Euro Euro Screw Vis “Euro” Wood Dowel Goujons de bois Green Twister Dowel Goujon de torsion vert Screw green twister dowels and wooden dowels into the left...
- Page 5 Step 2 Estimated Time: 10 Minutes Attach metal cabinet slides to black spacers on left (C3) and right (C4) sides with Euro screws Attachez les glissières de coffret en métal aux côtés gauche (C3) et droit (C4) en utilisent les vis “Euro” Position glide with wheel to the front and the bottom Placez le glissement avec la...
- Page 6 Step 3 Estimated Time: 5 Minutes Insert cams into rear stabilizer (c6) Insérez les ferrures au renforcement arrière (C6) Insert cams in the unlocked position, with the opening facing toward the hole for the twister dowel. Insérez les ferrures dans la position déverrouillée, de façon à...
- Page 7 Step 4 Estimated Time: 5 Minutes Screw green twister dowels and wooden dowels into the front stabilizer (C7) where shown Vissez les goujons de torison vert et les goujons de bois au renforcement avant (C7) comme montre Attach front stabilizer (C7) to the left (C3) and right (C4) sides and lock cams using a flat head screwdriver Attachez le renforcement avant (C7) aux côtés gauche (C3) et droit (C4) et serrez les ferrures utilisant un...
- Page 8 Step 5 Estimated Time: 5 Minutes Screw green twister dowels into the top (C1) Vissez les goujons de torison vert au dessus (C1) Gently hammer plastic dowels into the edge of the top molding (C2) Martelez doucement les goujons en plastique dans le bord de la moulure supérieur (C2) Attach top molding.
- Page 9 Step 6 Estimated Time: 5 Minutes Screw green twister dowels into the side moldings (C5) Vissez les goujons de torison vert aux moulure latérale (C5) Insert cams into sides and attach the top (C1) and the side moldings (C5) as shown. Then, tighten cams. Insérez les ferrures aux côtés et attachez le dessus (C1) et les moulure latérale (C5) comme montre.
- Page 10 Step 7 Estimated Time: 5 Minutes Attach backer with nails (C8) Attachez le dos avec les clous (C8) Page 10 of 16...
- Page 11 Drawer Parts Pièces de tiroir Small Small Left Small Right Small Drawer Back (1) Drawer Bottom (3) Drawer Front (1) Drawer Side (1) Drawer Side (1) Arrière du tiroir petit Fond du tiroir petit DK-0418 DB-0414 Devant du tiroir petit Côté...
- Page 12 Step 8 ÉTAPE 8 Temps prévu : Estimated Time: 5 Minutes per Drawer 5 minutes PAR TIROIR Insert small cams into drawer sides Insérez les ferrures petite dans des côtés de tiroir Screw black twister dowels into drawer fronts Vissez les goujons torison noir dans des avants de tiroir Page 12 of 16...
- Page 13 Attach drawer sides to drawer back with 1½” Hi Lo screws Attachez les côtés de tiroir au dos de tiroir avec les vis noires avec 1 ½ po. Attach drawer front and tighten cams #8 - 1½” Hi Lo Screws Attachez le tiroir avant et serrez les cames Vis no.8 - 1½...
- Page 14 Turn drawer upside down and slide drawer bottom into grooves Tournez le tiroir à l’envers et glissez le fond de tiroir dans des cannelures Secure the drawer bottom to the drawer back with nails Fixez le fond de tiroir au dos de tiroir avec des clous Use 4 nails per drawer Employez 4 clous par tiroir Page 14 of 16...
- Page 15 Attach drawer slides to left and right drawer sides using drawer slide screws Attachez les glissements de tiroir aux côtés gauche et droit du tiroir avec les vis pour coulisse de tiroir Right Drawer Side Côté droit du tiroir Drawer Slide Screws Vis pour coulisse de tiroir Left Drawer Side Côté...
- Page 16 Step 9 Estimated Time: 1 Minute Insert drawers Insérez les tiroirs Cabinet Drawer Note: When drawers are installed correctly, you will not be able to remove them with- out first lifting up the drawer front. NOTE: Quand des tiroirs sont installés correctement, vous ne pourrez pas les enlever sans se soulever d’abord vers le haut de l’avant de tiroir.
