- Page 1 Owner’s Manual High Quality Window Type Room Air Conditioner MAY 110 RCA INST MANUAL...
-
Page 2: Table Of Contents
CONTENTS General Information Name and Function of Components Control Panel Preparations for Operation Cooling Operation Fan Operation Airflow Direction Adjustment Operation, Maintenance and Care Replacing the filter Precautions Before calling for Service RCA INST MANUAL... -
Page 3: General Information
GENERAL INFORMATION To ensure that the air conditioner to be used correctly and safely, please proceed the installation in accordance with the installation manual and read through this manual carefully before using the system. Please keep the manual in a safe place after use. This is window - type cooling air conditioner. -
Page 4: Name And Function Of Components
NAME AND FUNCTION OF COMPONENTS Air Outlet Grille Power Cord Plug Intake Grille Air Filter Pannel CONTROL PANEL Ventilation Control When the slide level is set at the Left (position of Off), the ventilation door will close. Then the indoor air can only be circulated and adjusted. -
Page 5: Preparations For Operation
PREPARATIONS FOR OPERATION Set the function control switch to “Off”. Insert the power plug, and turn on the power of the unit. Turn the temperature control switch to position to “10” (the coolest) and make preparations for other operations. Hi Fan Lo Fan Lo Cool Hi Cool... -
Page 6: Fan Operation
FAN OPERATION High Fan Hi Fan Turn the function switch to “Hi Fan”. Lo Fan Lo Cool At this time the fan will operation in high speed, and the compressor will stop Hi Cool operation except for the ventilation of the room and eliminate dust. SELECTOR Low Fan Turn the function switch to “Lo Fan”. -
Page 7: Operation, Maintenance And Care
OPERATION, MAINTENANCE AND CARE Remember the following suggestions so as to improve the cooling efficiency of the unit , to reduce noise and save electricity costs. Pull the curtains close. Direct sunlight reduces the cooling efficiency of the air conditioners . So the curtain must be pull close Do not install near a heat source. -
Page 8: Precautions
PRECAUTIONS The drain outlet is set in the back at the bottom left of the body. Please select a correct draining method in accordance with the installation manual. Please turn off the air-conditioner, turn off the power and inform the service center immediately in the following cases. -
Page 9: Before Calling For Service
PRIOR TO CALLING FOR SERVICE Check the listed conditions in the followings. Perhaps you may find the solutions for the problems and save time and money as well. Not operating Is the power cord connected to the power source? Is the circuit breaker or fuse open or broken? - Close the circuit breaker again or replace the fuse. - Page 10 FAX: (09) 820 0332 517A Rosebank Road Avondale, Auckland NZ NZ Tech Support Freecall TEL: 0800 180 094 www.airwell.com.au WITH A CONCERN FOR A CONSTANT IMPROVEMENT, OUR PRODUCTS CAN BE MODIFIED WITHOUT NOTICE. PHOTOS NON CONTRACTUAL. © Copyright 2003 RCA INST MANUAL...
