assembly instructions
ILS120 - illuminated double-sided ReFrame®
2
Stack corner brackets as pictured - the bracket with screws goes on top and the blank bracket on the bottom
3
Insert the stacked corner brackets into the channels of the top and bottom lengths of frame (screws may need to be
loosened to allow brackets to slide into position)
NOTE: To ensure a precise line-up of the frame profiles, do not tighten any of the screws until you have reached step 7
www.afibranding.com.au
|
1300 652 514
|
33 Lakewood Blvd, Carrum Downs, Vic, 3201
1
1
Lay out the ReFrame®
components on a flat
surface and ensure you have
everything required before
you start the assembly.

CHECKLIST

8x
Corner Brackets
4x
ReFrame® Lengths
1x
ReFrame® Power
Adapter
1x
Allen Key

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ReFrame illuminated double-sided and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AFi ReFrame illuminated double-sided

  • Page 1 assembly instructions ILS120 - illuminated double-sided ReFrame® Lay out the ReFrame® components on a flat surface and ensure you have everything required before you start the assembly. CHECKLIST Corner Brackets ReFrame® Lengths ReFrame® Power Adapter Allen Key Stack corner brackets as pictured - the bracket with screws goes on top and the blank bracket on the bottom Insert the stacked corner brackets into the channels of the top and bottom lengths of frame (screws may need to be loosened to allow brackets to slide into position) NOTE: To ensure a precise line-up of the frame profiles, do not tighten any of the screws until you have reached step 7...
  • Page 2 (not shown on this fact sheet), accessories, or has bends/curves and you are unsure how to proceed with assembly, please contact the team at AFI Branding on 1300 652 514 and we will guide you through the assembly process. Developed by AFI Branding www.afibranding.com.au...
