assembly instructions
SS108 - single-sided ReFrame®
2
Insert corner brackets into the channels of the top and bottom lengths of frame (screws may need to be loosened to
allow brackets to slide into position)
NOTE: To ensure a precise line-up of the frame profiles, do not tighten any of the screws until you have reached step 6
3
Slide top and side length together
www.afibranding.com.au
4
|
1300 652 514
|
33 Lakewood Blvd, Carrum Downs, Vic, 3201
1
1
Lay out the ReFrame®
components on a flat
surface and ensure you have
everything required before
you start the assembly.
CHECKLIST
4x
4x
1x
Repeat on the opposite corner so that 3 lengths are
connected
Corner Brackets
ReFrame® Lengths
Allen Key
