CAM_TRIG
SWO
Board Dimensions
The board is 3.30"x2.20". There are 4x mounting holes on each corner of the board.

Hardware Hookup

If you have not already, make sure to check out the Getting Started with MicroMod: Hardware Hookup for
information on inserting your Processor Board to your Carrier Board.
D1 18
I2C_INT# 16
I2C_SCL (I/0)) 14
I2C_SDA (I/0) 12
D0 10
G11 8
RESET# (I - 6
Open Drain)
3.3V_EN 4
3.3V 2
17 UART_RX1 (0)
15 UART_CTS1
(I)
13 UART_RTS1
(O)
11 BOOT (I -
Open Drain)
9 USB_VIN
7 GND
5 USB_D-
3 USB_D+
1 GND
