- Page 1 F-20L Helium Compressor Operating Manual Sumitomo (SHI) Cryogenics of America, Inc. 1833 Vultee Street Allentown, PA 18103-4783 U.S.A. Revision B: September 2021 280358A...
-
Page 3: Table Of Contents
Helium Compressor, Model F-20L ..............7 PRINCIPLES of OPERATION ..................9 DESCRIPTION ......................11 Components ..................... 11 SPECIFICATIONS ....................... 13 F-20L Compressor (low voltage model) ............. 13 Electrical Characteristics ................. 13 Power Consumption ..................13 Compressor Control ..................14 Front Panel Connections ................... 14 Front Panel Mounted Items ................ - Page 4 Figure 16 Connect Self-Sealing Coupling ............37 Figure 17 Leak Check Aeroquip Couplings ............. 38 Figure 18 Fuse Holders on F-20L Front Panel ..........43 Figure 19 F-20L Compressor Wiring Diagram ..........49 Figure 20 F-20L Compressor Wiring Schematic..........50 Figure 21 Adapter Fitting, 8F with Valve ............
-
Page 5: Safety
SAFETY GENERAL SCAI equipment is designed to operate safely when the installation, operation and servicing are performed in accordance with the instructions in this technical manual. For Service Center locations, see the Service section of this manual. SPECIAL NOTICES Three types of special notices -- WARNINGS, CAUTIONS and NOTES are used in this technical manual. - Page 6 Safety WARNINGS AVOID ELECTRIC SHOCK. This equipment must only be connected to a supply mains switch with protective earth. All electrical supply equipment must meet applicable codes and be installed by qualified personnel. If this equipment is modified, appropriate inspection and testing must be conducted to ensure safe use of equipment.
- Page 7 Safety CAUTIONS PRESERVE YOUR WARRANTY. Modification to equipment without the consent of the manufacturer will void the warranty. Specifications require the use of 99.995% pure helium gas. Using a lesser quality of helium can damage the system and void the warranty. AVOID GAS LEAKS.
- Page 8 Safety AVOID EQUIPMENT FAILURE, CONTAMINATION OR A NUISANCE SHUTDOWN. Do not tip the compressor greater than 5 degrees from horizontal, to avoid flowing oil into unwanted places. Use SHIG adsorber P/N F300138A only. Use of non-SHIG spare parts will void the warranty.
-
Page 9: Service
SERVICE U.S.A. HEADQUARTERS Sumitomo (SHI) Cryogenics of America, Inc. 1833 Vultee Street Allentown, PA 18103-4783 Sales and Parts TEL: (800) 525-3072 (610) 791-6700 FAX: (610) 791-0440 Service TEL: (800) 525-3071 TEL: (610) 791-6750 SERVICE CENTERS Central Sumitomo (SHI) Cryogenics of America, Inc. - Page 10 (This page is intentionally blank.)
-
Page 11: Introduction
Self-sealing gas couplings allow for easy connection to and disconnection from the rest of the closed-cycle cryogenic refrigeration system. The information in this manual pertains only to the F-20L (low voltage model) Compressor. Other components used to form an operating system are described in separate technical manuals. - Page 12 (This page is intentionally blank.)
-
Page 13: Principles Of Operation
PRINCIPLES of OPERATION Figure 1 Compressor Flow Diagram Helium discharge temperature switch Atmospheric relief valve Internal relief valve Solenoid valve Pressure gauge Oil discharge temperature switch Water-out temperature switch The compressor continuously draws low-pressure helium from the system return line. It compresses, cools and cleans the gas, then delivers it through the system gas supply line to the cold head. - Page 14 Principles of Operation When helium gas leaves the compressor capsule, the gas contains heat and compressor lubricant. Both must be removed. From the compressor capsule, the hot gas with its entrained oil flows out of the shell and through the bulk oil separator. The gas next flows through one circuit of a three-circuit, water cooled, heat exchanger, where it is cooled.
-
Page 15: Description
DESCRIPTION Components 50/60 Hz Toggle Switch - This switch on the front electrical panel is used to select different phasing circuits for RDK-101D cold head operations at 50 or 60 Hz. Accessory Receptacle and optional Remote ON/OFF cable - The accessory receptacle on the front electrical panel is a 4-socket connector for supplying remote ON/OFF capability. - Page 16 Description Gas Equalization Solenoid Valve – This solenoid valve opens when the compressor shuts down, allowing helium gas pressure to equalize and prevent oil from moving into low pressure side of compressor. Gas Supply and Return Couplings - Located on the compressor front electrical panel, both are self-sealing, size #8, male bulkhead couplings and are the points of connection for system gas lines.
-
Page 17: Specifications
280090D27N 220 - 240 VAC +/- 10%, V~ 50 Hz Electrical Characteristics Service required: 2 poles, 3 wires (single phase plus protective ground.) Mains Power Receptacle F-20L: Phoenix Heavycon Advance – Type HC-B10-TMS with screw locks. Power Consumption Variation Frequency... -
Page 18: Compressor Control
Automatic shutoff for the following system faults. Operator correction is required before • restart. High helium gas discharge temperature [TSG] when > 93° C (200° F) • High compressor motor windings temperature. • F-20L P/N Switch Opens Switch Resets 280090D18N 145° C 69-87° C (293° F) (156-189°... -
Page 19: Mounting Position
Specifications NOTE Operating the equipment out of specifications may void the warranty. Mounting Position Compressor must be mounted base down and level within 5 degrees of horizontal. Cooling Requirements Cooling water flow rate: 1.9-3.8 L/min (0.5-1.0 GPM) Cooling water inlet temperature: 4 to 27°... -
Page 20: Helium Gas Pressures
Specifications Helium Gas Pressures Equalization Pressure Application Flex Gas Line at 20° C (68° F) RDK-101D Cold Head, 50/60 Hz 240 psig ؽ ” x 20 ft (6m) ① ؽ ” x 10 ft (3m) ② CH-104 Cold Head, 50/60 Hz 240 psig ؽ... -
Page 21: Weight
Normal pressure and temperature data are listed above. User should record monthly the operating conditions in a logbook. Keep this record of data for reference and later comparisons. Supplier Name and Address Sumitomo (SHI) Cryogenics of America, Inc. 1833 Vultee Street Allentown, PA 18103-4783 U.S.A. -
Page 22: Regulatory Compliance
Specifications Regulatory Compliance EU Declaration of Conformity Manufacturer’s Name Sumitomo (SCAI) Cryogenics of America Manufacturer’s Address 1833 Vultee Street Allentown, PA 18103 U.S.A. Type of Equipment Cryogenic Refrigeration Systems We declare under our sole responsibility that the following product(s) F-20L Series Compressor... - Page 23 Specifications Figure 2 F-20L Compressor, Front View...
- Page 24 Specifications Figure 3 F-20L Compressor, Dimensions Dimensions are in inches and [mm].
-
Page 25: Installation
INSTALLATION Introduction Install the F-20L Compressor, Mains Power Cable and the Gas Lines according to the following procedures. The following installation procedures are based on standard arrangements of equipment, using SCAI standard components. To prevent contaminating the components or the system, it is important to follow the procedures in this manual step by step. -
Page 26: Unpackaging And Product Inspection Instructions
Installation 2.2 Look through the “peep hole” on the container. View the pressure gauge on the Compressor Unit front panel. The pressure gauge should indicate equalization pressure shown in specification section. 2.3 If the gauge indicates 0 PSIG (0 MPa), the Compressor Unit cannot be used. Contact the nearest SHIG Service Center. - Page 27 Installation 2. Inspect the Tip-N-Tell Sensor on Compressor Unit for Activation. 2.1 Check the Tip-N-Tell sensor mounted on the compressor rear panel. If the Tip-N- Tell sensor shows no mishandling and there is no apparent physical damage, skip Steps 2.2 and 2.3 and proceed to the section Compressor Location. If the Tip-N-Tell sensor indicates mishandling (arrow dot is red), proceed to either Step 2.2 or 2.3: 2.2 The equalization pressure is within specifications:...
-
Page 28: Compressor Location
Tool required: #3 Phillips screwdriver 5 mm Hex driver The F-20L compressor must be installed in a circuit capable of supplying the specified voltage and power. The wiring method used for connection to the front panel power connector must meet applicable codes. -
Page 29: Coolant Connections
Installation Figure 4 Connect Mains Power Supply Cable to Mains Power Receptacle Coolant Connections Tools required: Open-end wrench, 15/16” Open-end wrench to suit customer’s water lines fittings Using two wrenches, connect coolant supply and return lines to the water in and water out fittings on the front of the compressor. -
Page 30: Compressor Checkout
Installation Hold hex with 15/16” open end wrench. Turn water line coupling with the other wrench. Figure 5 Connect and Remove the Water Lines PREVENT EQUIPMENT DAMAGE. Always thoroughly drain the coolant from the cooling circuit if the compressor is to be shipped or stored. Compressor Checkout The compressor should be operated before being connected to the other system components. -
Page 31: Install The Gas Lines
Installation Install the Gas Lines Tool required: Open-end wrenches, 1", 1 1/8", 1 3/16" Gas lines are shipped with protective dust plugs. Do not remove the plugs until the gas lines are ready to be attached. All bending and routing of gas lines should take place with plugs in place. -
Page 32: Install The Cold Head Cable(S)
Installation 4. Connect the gas lines to the compressor’s high-pressure (supply) and low-pressure (return) couplings. Use two wrenches to tighten the coupling. Torque all couplings to 47 ± 7 Nm (35 ± 5 ft. lbs.) See Figure 7. Tighten each coupling before proceeding to the next one. AVOID GAS LEAKS. -
Page 33: Remote On/Off Cable (Optional Accessory)
Installation Remote On/Off Cable (Optional Accessory) A remote on/off cable can be furnished as an accessory. See the Parts section for part number and ordering. 1. Disconnect the power to the compressor. 2. Remove the heat shrink cap from one end of the remote on/off cable. Connect the cable to customer’s remote switch. - Page 34 (This page is intentionally blank.)
-
Page 35: Operation
OPERATION Starting Close the circuit breaker by pushing up the handle. Press the power switch. The indicator in the switch will light. The compressor will start. Any items drawing power from the compressor will start. PREVENT EQUIPMENT DAMAGE. After starting the system for the first time, to be certain that the water lines are properly connected, check that the outlet water temperature is warmer than the inlet water. - Page 36 (This page is intentionally blank.)
-
Page 37: Maintenance
MAINTENANCE Adsorber Replacement Part required: Adsorber, P/N F300138A Tools required: #2 Phillips screwdriver Open-end wrenches, 1", 1 1/8", 1 3/16" ® Snoop AVOID EQUIPMENT FAILURE OR CONTAMINATION. Use SHIG adsorber P/N F300138A only. Use of non-SHIG spare parts will void the warranty. The compressor’s adsorber should be replaced every 30,000 operating hours (40 months). - Page 38 Maintenance 4. Using two wrenches, disconnect the self-sealing coupling on the inlet side of the adsorber. See Figure 9. Figure 9 Disconnect Self-Sealing Coupling 5. Use a Phillips screwdriver to remove the two screws holding the adsorber to the base. See Figure 10.
- Page 39 Maintenance 6. Remove the locknut on the Aeroquip supply coupling on the front panel. See Figure 11. Figure 11 Remove Supply Coupling Locknut 7. Pull the adsorber back until the supply coupling clears the front panel. Remove the adsorber. Remove the lock washer from the Aeroquip supply coupling. Retain all hardware to reuse with the new adsorber.
-
Page 40: Adsorber Installation
Maintenance Adsorber Installation 1. Remove the dust caps from the gas couplings of the new adsorber. Do not vent the new adsorber. 2. Install the lock washer on to the supply coupling of the new adsorber. Insert the supply coupling through the front panel and position the adsorber. See Figure 13. Figure 13 Install Lock Washer on Adsorber 3. - Page 41 Maintenance 4. Install the red nylon washer and the locknut on the supply coupling. Torque the locknut to 54 Nm (40-ft. lbs.). See Figure 15. Figure 15 Install Supply Coupling Washer and Locknut 5. Connect the adsorber’s self-sealing coupling on its inlet side to the oil separator’s outlet coupling.
- Page 42 Maintenance 6. Reconnect the supply (red) gas line to the supply coupling on the compressor. Torque the coupling to 47 ± 7 Nm (35 ± 5-ft. lbs.). ® ® 7. Using Snoop , leak check all Aeroquip couplings just completed. Wipe off the Snoop prevent rusting.
-
Page 43: Used Adsorber Venting And Disposal
Maintenance Used Adsorber Venting and Disposal For safe disposal of the used adsorber: 1. A venting adapter fitting is included with the new adsorber. Attach it to one of the self- sealing couplings on the used adsorber. Vent the used adsorber to atmospheric pressure. 2. -
Page 44: Venting Procedure To Adjust Equalization Pressure
Maintenance To charge helium gas to the system: 1. Stop the compressor. 2. Locate charge and vent tool, P/N 267191A, and bleed adapter, P/N 267192A. Screw bleed adapter into charge and vent tool. 3. Connect the charge line from the pressure regulator of a helium gas cylinder containing 99.999% pure helium with a dew point less than -62°... -
Page 45: Gas Cleanup
Maintenance Gas Cleanup Tools required: 2 adapter fittings with valve, 8F Aeroquip, 255919B2. Open-end wrenches, 1", 1 1/8" and 1 3/16". Helium gas cylinder with pressure regulator and charge line. If the equalization pressure shown by the compressor’s pressure gauge is less than 1.4 bar (20 psig), gas cleanup of the compressor is required. -
Page 46: Fuse Replacement
Fuse Replacement Tool required: Flat screwdriver Fuses for the F-20L are located in the front panel of the electrical chassis of the compressor Control circuit (FU-1, FU-2, FU-3 and FU-4 ) as shown in Figure 18: a. Four (3) 1AT , 250V... -
Page 47: Troubleshooting
2. Open fuse holder with flat screwdriver and Remove open fuse from fuse holder and replace with new fuse of same ampere rating. Fuse Holder Figure 18 Fuse Holders on F-20L Front Panel... - Page 48 (This page is intentionally blank.)
- Page 49 TROUBLESHOOTING Automatic Shutdown The compressor will not start or will shut down automatically if any of the following are open: the compressor motor protector switch; • the water, oil or gas high-temperature switch; • the motor over-current relay; • the circuit breaker. •...
- Page 50 Troubleshooting PRESERVE YOUR WARRANTY. Modification of equipment without the consent of the manufacturer will void the warranty. Troubleshooting Guide The Troubleshooting Guide that follows lists problems that can occur in the system and suggests causes and corrective actions. Problem Possible Cause Corrective Action Compressor and items No electrical power.
- Page 51 Troubleshooting Problem Possible Cause Corrective Action Compressor starts but shuts Water high-temperature Check the coolant flow and down sometime later. switch is open. temperature. Refer to the Specifications. Circuit breaker or fuse is Reset the Circuit breaker or open. replace a fuse. Compare the electric service with system specifications.
- Page 52 Troubleshooting Problem Possible Cause Corrective Action Compressor runs, but cold Wrong cold head cable. Ensure correct cold head head valve motor operation is cable is connected per “Install abnormal. the Cold Head Cable(s)” procedure and visual inspection. Cold head problem. Consult cold head manual.
- Page 53 Troubleshooting Figure 19 F-20L Compressor Wiring Diagram...
- Page 54 Troubleshooting Figure 20 F-20L Compressor Wiring Schematic...
-
Page 55: Parts
Refer to the next section for Parts Identification and Numbers. Installation Tool Kit The following installation tool kit is used for installing or servicing the F-20L compressor and is available as an accessory from SCAI Installation tool kit P/N 267990A consists of:... -
Page 56: Cables
Parts Cables The following cables are available for use with the F-20L Series Compressors as accessories from SCAI. Item Quantity Description Part Number Mains Power Supply Cable, F-20L, 3 m (10 ft.) 280112C10 long. Remote On/Off Cable, 6 m (20 ft.) long.
