Model: LCIT RT5060 (D516)
Subject:
Firmware Release Note: LCIT RT5060
From:
PPBG Service Planning Dept.
Classification:
This RTB has been issued to announce the firmware release information for the LCIT.
Version
Program No.
01.030:04
Note: Definition of Availability of RFU via @Remote
"Available": The firmware can be updated via RFU or SD card.
"Not available": The firmware can only be updated via SD card.
Version
01.030:04
1st Mass production
T
echnical
Troubleshooting
Mechanical
Paper path
Product Safety
D5165510B
Modified Points or Symptom Corrected
B
ulletin
Date: 20-Jun-11
Prepared by:
Part information
Electrical
Transmit/receive
Other (Firmware)
Effective Date
1st Mass production
PAGE: 1/1
No.: RD516001
K.Tsutsui
Action required
Service manual revision
Retrofit information
Tier 2
Availability of RFU
Available

Advertisement

loading
Need help?

Need help?

Do you have a question about the LCIT RT5060 and is the answer not in the manual?

Questions and answers

Related Manuals for Ricoh LCIT RT5060

Summary of Contents for Ricoh LCIT RT5060

  • Page 1 PAGE: 1/1 Model: LCIT RT5060 (D516) Date: 20-Jun-11 No.: RD516001 Subject: Prepared by: Firmware Release Note: LCIT RT5060 K.Tsutsui From: PPBG Service Planning Dept. Troubleshooting Part information Action required Classification: Mechanical Electrical Service manual revision Paper path Transmit/receive...
  • Page 2 echnical ulletin PAGE: 1/2 Model: Date: No.: Aegis-C1 (D016) 23-Jan-12 RD016018 Subject: Prepared by: Part Changes; Handle assembly and Shoe A. Takada From: PP Tech Service Dept., 1st PP Tech Service Sect. Troubleshooting Part information Action required Classification: Mechanical Electrical Service manual revision Paper path Transmit/receive...
  • Page 3 ・ If the unit is now installed with D3553566, replace with D3553567. D5163847 is not needed. ・ D5163847 can be attached ONLY to D3553567. ・ The modification described in this bulletin also applies to Aries C-1.5 (D095), LCT RT5020 (D355), LCIT RT5050 (D532), and LCIT RT5060 (D516).
  • Page 4 PAGE: 1/1 Model: Date: No.: Taurus-C1/P1 (D074/D075/M044) 15-Feb-12 RD516002 Subject: Parts Number Information (Tray Heater for Prepared by: T. Komori Taurus-C1/P1 LCIT RT5060) From: 1st Tech Service Sect., PP Tech Service Dept. Troubleshooting Part information Action required Classification: Mechanical Electrical...
  • Page 5 echnical ulletin PAGE: 1/1 Model: Date: No.: Large Capacity Tray RT5060 (D516) 26-Mar-12 RD516003 Subject: Prepared by: Part Changes (Slide Rails) S. Sasaki From: 1st PP Tech Service Sec., PP Tech Service Dept., Troubleshooting Part information Action required Classification: Mechanical Electrical Service manual revision Paper path...
  • Page 6 echnical ulletin PAGE: 1/5 Model: Date: No.: Large Capacity Tray RT5060 (D516) 22-May-2012 RD516004 Subject: Post card fence attachment procedure Prepared by: K. Tsutsui From: 1st PP Tech Service Section, PP Tech Service Dep. Troubleshooting Part information Action required Classification: Mechanical Electrical Service manual revision...
  • Page 7 echnical ulletin PAGE: 2/5 Model: Date: No.: Large Capacity Tray RT5060 (D516) 22-May-2012 RD516004 2. Pull to remove the snap-fit retainer ring. 3. Lift up to clear the auxiliary post card fences from the 2 shafts. Remove the fences (x4) one at a time. 4.
  • Page 8 echnical ulletin PAGE: 3/5 Model: Date: No.: Large Capacity Tray RT5060 (D516) 22-May-2012 RD516004 5. Check that the removed parts are as shown below. Tray 3 (1,000 sheets) Tray 4 (2,000 sheets) Tray 5 (1,000 sheets) 6. Apply the short fences for Trays 3 or 5, and the long fences for Tray 4. Attachment procedures are identical for all trays.
  • Page 9 echnical ulletin PAGE: 4/5 Model: Date: No.: Large Capacity Tray RT5060 (D516) 22-May-2012 RD516004 7. Attach the U-shaped hook to the bolt located at the bottom of the side plate (rear). 8. Fix the post card fence by aligning the boss and screwing the green knob screw. Align the hole on the fence with the boss on the side plate.
  • Page 10 echnical ulletin PAGE: 5/5 Model: Date: No.: Large Capacity Tray RT5060 (D516) 22-May-2012 RD516004 9. Check that the post card fence is installed as shown in the photos below. Install the opposing fence (front) similarly. NOTE: To remove the post card fences, follow the above steps in the reverse order.

  • Page 11: Troubleshooting

    echnical ulletin PAGE: 1/3 No.: RD453008 Model: Date: LCIT RT4000 (D350) / RT5040 (D453) / RT5060 2-Jul-13 (D516) / RT5030 (D452) Subject: Broken Casters on LCIT Prepared by: S. Sasaki From: PP Tech Service Sec., PP Tech Service Dept. Troubleshooting Part information Action required Classification:...
  • Page 12 Caster Replacement Procedure IMPORTANT: 3 persons are required to secure working safety. 1. Remove all trays from the LCT. See the following section of the field service manual. LCIT RT5040, LCIT RT5060 1. Replacement and Adjustment > Removing Trays LCIT RT4000 1.
  • Page 13 V5721200001 to V5721200043 V5721200044 to V5721200110 V5730100001 to V5730100116 V5730200032 to V5730200063 V5730200001 to V5730200031 V5730300051 to V5730300102 V5730300001 to V5730300050 LCIT RT5060 EU/AP W0121100001 to W0121100181 W0121100182 to W0121100207 W0121200001 to W0121200224 None W0130100001 to W0130100178 W0130200001 to W0130200043...
  • Page 14 echnical ulletin PAGE: 1/7 Reissued:5-Dec-13 Model: Date: No.: Large Capacity Tray RT5060 (D516) 6-Nov-13 RD516005 RTB Reissue The items in bold italics were corrected or added. Subject: Prepared by: Procedure for preventing JAM80 and Skews on LCT Shinnosuke Sasaki From: 1st PP Tech Service Sec., PP Tech Service Dept., Classification: Troubleshooting...
  • Page 15 D0749911: BEARING:KIT IMPORTANT: Information exclusive for Ricoh Europe In addition to the s/n, check if a green dot (as shown in the photo below) is attached to the left side of the s/n label. If attached, the machine has already been reworked at RPL and therefore rework is unneeded even if the machine has an affected s/n.
  • Page 16 echnical ulletin PAGE: 3/7 Reissued:5-Dec-13 Model: Date: No.: Large Capacity Tray RT5060 (D516) 6-Nov-13 RD516005 3. Follow the instructions below to replace the white plastic roller with a set of 2 ball- bearings (p/n: D0749910). Keep the front left door closed during this procedure. Remove the E-ring, pin and the plastic roller (old part).
  • Page 17 echnical ulletin PAGE: 4/7 Reissued:5-Dec-13 Model: Date: No.: Large Capacity Tray RT5060 (D516) 6-Nov-13 RD516005 3-2) Insert a tool approximately 3mm wide in between the retraction arm (white part) and the ball-bearings from the bottom so that the bearings shift to the rear.
  • Page 18 echnical ulletin PAGE: 5/7 Reissued:5-Dec-13 Model: Date: No.: Large Capacity Tray RT5060 (D516) 6-Nov-13 RD516005 5. Insert the jig (made of hard styrene foam) in the guide plate at the center, and wait for approx 30 seconds. Then, repeat the Step 4 to check the results. Fully insert the jig until it stops.
  • Page 19 echnical ulletin PAGE: 6/7 Reissued:5-Dec-13 Model: Date: No.: Large Capacity Tray RT5060 (D516) 6-Nov-13 RD516005 Affected Serial Numbers W0130300073 W0130300101 W0130400069 W0130500050 W0130600046 W0130600119 W0130600157 W0130300074 W0130300102 W0130400070 W0130500051 W0130600047 W0130600120 W0130600158 W0130300075 W0130300103 W0130400071 W0130500055 W0130600048 W0130600121 W0130600159 W0130300076 W0130300105 W0130400072 W0130500056...
  • Page 20 echnical ulletin PAGE: 7/7 Reissued:5-Dec-13 Model: Date: No.: Large Capacity Tray RT5060 (D516) 6-Nov-13 RD516005 W0130400009 W0130400051 W0130500019 W0130500075 W0130600041 W0130600112 W0130400011 W0130400052 W0130500020 W0130500081 W0130600042 W0130600113 W0130400012 W0130400053 W0130500021 W0130500082 W0130600043 W0130600116 W0130400013 W0130400054 W0130500022 W0130500083 W0130600045 W0130600128 W0130400014 W0130400055 W0130500023 W0130500084...
  • Page 21 echnical ulletin PAGE: 1/4 Model: Date: No.: Large Capacity Tray RT5060 (D516) 17-Dec-13 RD516006 Subject: Prepared by: Threading the screw holes for mounting the Multi Shinnosuke Sasaki Bypass Tray unit From: 1st PP Tech Service Sec., PP Tech Service Dept., Classification: Troubleshooting Part information...
  • Page 22 echnical ulletin PAGE: 2/4 Model: Date: No.: Large Capacity Tray RT5060 (D516) 17-Dec-13 RD516006 CAUSE Screw holes in the bracket are not threaded due to a fault in the manufacturing process. GOOD Not threaded Threaded Affected Serial Numbers See the last page of this bulletin. SOLUTION 1) Before visiting customer sites to install the Multi Bypass Tray unit, procure the following self-tapping screws (p/n: D0749912) in advance.
  • Page 23 echnical ulletin PAGE: 3/4 Model: Date: No.: Large Capacity Tray RT5060 (D516) 17-Dec-13 RD516006 Procedure 1. Remove the top left cover. 2. Locate the affected screw holes(s) for the joint pins and thread them by screwing in the self-tapping screws. IMPORTANT: Screw in the self-tapping screw straight against the bracket, without an angle.
  • Page 24 echnical ulletin PAGE: 4/4 Model: Date: No.: Large Capacity Tray RT5060 (D516) 17-Dec-13 RD516006 Affected Serial Number List RAC: 97 Units W0130500003 W0130500023 W0130500046 W0130500073 W0130500095 W0130600004 W0130500005 W0130500026 W0130500048 W0130500074 W0130500096 W0130600010 W0130500007 W0130500027 W0130500049 W0130500075 W0130500097 W0130600013 W0130500008 W0130500030 W0130500052 W0130500081 W0130500098 W0130600014 W0130500009 W0130500031 W0130500053 W0130500082 W0130500112 W0130600016 W0130500010 W0130500032 W0130500054 W0130500083 W0130500113 W0130600033 W0130500011 W0130500033 W0130500059 W0130500084 W0130500114 W0130600037...
