Clevertronics CLP CCIRC Series Installation & Maintenance Instruction Leaflet

Clevertest and Clevertest Plus
Refer to the supplementary operation guide supplied with the Product.
After Power ON, the Status LED on a Clevertest Plus enabled fitting will display a rapid Green or Red
flashing for a period up to 2 minutes.
Note: To scan Status LED on the fitting, ring and lid at the front of Bunkalite needs to be removed.
Status LED Note:
Status LED is High Brightness and may appear as two separate spots as
illustrated. If Red and Green are seen at the same time, this needs to be taken
as Yellow in this Clevertest Plus operation guide.
Zoneworks, HIVE and DATA Monitored Options
Fittings with part numbers -ZW, -HVG, -DATA are fitted with Zoneworks communications modules
(nodes). These fittings are monitored using either Powerline Carrier Technology that utilize the power
cable to provide data communication, RF transceiver modules operating in the ISM band or a dedicated
data cable to/from data routers installed on a dedicated data trunk connected to a central Server (can also
be connected via Ethernet/Internet/Fibre). Zoneworks software on the server is used to monitor,
coordinate testing and collate test data from each fitting. Zoneworks Fittings can be commissioned by a
single push of the test switch or by scanning the supplied barcode. The LED Test Switch indicator provides
a multifunction indication of the status of the fitting during testing and normal operation:
Option State
ZW, HVG, DATA Commissioned
ZW, DATA Un-commissioned
Un-commissioned
HVG
With network connectivity
Un-commissioned
HVG
Without network connectivity
ZW, DATA Emergency Light Test In Progress
HVG Emergency Light Test In Progress
In the case of the DATA version a 2-way "figure 8" cable and terminal block facilitates the connection to
the DATA network via a multi-drop bus (daisy chain connection). For further information of installation of
a Zoneworks system, please refer to the Zoneworks Users Guide and Commissioning Guide (incl. DATA
version)
DALI EM Option
Luminaires with part numbers having -DALI are fitted with DALI modules (nodes) that facilitate connection
and integration to 3 rd Party Lighting Control Systems. Before installing the -DALI fitting please confirm
that the Lighting Control System has the capability to monitor DALI Emergency Luminaires. The -DALI
fitting will be addressed and configured into the control system by the Lighting Control System
Commissioning Technicians and not Clevertronics.
State LED Operation
Commissioned/ Un-commissioned LED on Solid (Green)
Emergency Light Test in progress LED flashes at 1s On (red & green) & 1s Off
"IDENTIFY COMMAND" Fitting goes into emergency mode for 10 seconds
A 2-way "figure 8" cable and terminal block facilitates the connection to the DALI network OR a 5/6way
"structured wiring system" lead and plug facilitating the power and DALI connection. DALI connections
are marked as Da Da.
LED Operation
LED on Solid (Green)
Batt plugged-in: red & green 1s, green 1s
Batt unplugged: red 1s, off 1s
Batt plugged-in: red & green 1s, green 1s
Batt unplugged: red 1s, off 1s
Batt plugged-in: red & green 1s 250mS, green
250mS, red & green 1s 250mS, green 250mS,
green 1s
Batt unplugged: red 250mS, off 250mS, red
250mS,off 250mS, off 1s
LED flashes at red & green 1s 5s , 0ff 1s
LED flashes at red & green 1s 1s , 0ff 1s
CLP™ Circular Emergency Light
Installation & Maintenance Instruction Leaflet
NOTE: Standard product codes with this symbol
are enabled with Clevertest Plus capability.
Please refer to the operation guide supplied with
the product for details.
Models: CCIRC-yy-xx
Testing:
Manual Test xx = Blank
Zoneworks xx = ZW
Z/W DATA xx = DATA
DALI Registered. xx = DALI
Hive xx = HVG
Spare Parts:
1550230 BATT:LP 3.2V 6400mAh.200mm lead.Brkt.
8002801 PCA: CLE 220mm 2500lm 840 ADV4 EM SO
1330041 LED Driver - Set to 380mA
UKM02370110001 CLIFE-CKIT-IC1-650
UKM02870060001 CLIFE-CKIT-HVG-IC1-650
Important:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant British Standards.
Australia (Head Office)
Website: www.clevertronics.com.au
Email: info@clevertronics.com.au
Phone: +61 3 9559 2700
Fax: +61 3 9559 2799
UK OFFICE
362 Stockley Close
West Drayton UB7 9BL
Phone: 01895 430 255
Options:
DALI Driver vv = DD
1942384 V1.0 25 June 2020
